Productos

Cien años en el jardín japonés de Huntington: armonía con la naturaleza

$ 45.00 USD

Durante más de cien años, el Jardín Japonés de Huntington ha servido como indicador del...

Ver todos los detalles del producto »

Onset 1.8 m Self-Describing Pipe Temperature Sensor

Request Quote

What measurements does this sensor support?

The SD-TEMP-P-06 sensor supports the following measurements: Temperature and soil temperature.

In what environment does this sensor operate?

This sensor operates in both indoor and outdoor environments.

Features

• Self-describing technology for quick and easy setup
• Locking connector to ensure the sensor is connected and stays connected
• Measurement range of -40° to 100°C
• Accuracy of ±0.15°C from 0° to 70°C
• Available in 1.8 m length
• Faster response time
• Suitable for pipe mounting

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Measurement Range	-40°C to 75°C
  Temperature Accuracy	±0.15°C from 0° to 50°C, probe must be inserted at least 2.3 cm
  Temperature Resolution	0.002° at 25°C
  Temperature Drift	<0.1°C per year
  Response Time in Air	Typical 2 minutes to 90% in air moving at 1 m/s
  Response Time in Pipe	Typically 2 times faster than the air/water/soil temperature sensor, typically less than 1 minute to 90%
  Probe Housing	Copper-coated sensor tip
  Probe Dimensions	0.9 x 5.8 cm
  Cable Length	1.8 m

• • Onset 1.8 m Self-Describing Pipe Temperature Sensor (1)
• • None
• • None
• Technical Specifications Manual (English)
• Data Sheet

(LC 20220629)

Ver todos los detalles del producto »

Adaptador de alimentación de CA Onset para estaciones HOBO U30

Request Quote

Ver todos los detalles del producto »

Sensor de CA de núcleo dividido Onset Amp

Request Quote

Onset CTV-C 10 - 100 Amp Split-Core AC Current Sensor

Safely and efficiently measure energy consumption with a split-core design that enables fast installation without interrupting the power supply.

The Onset CTV-C is a high-performance AC current sensor specifically designed for use with HOBO U12, UX120, and ZW series data loggers equipped with external input channels. This sensor accurately monitors ranges from 10 to 100 Amps AC in single-phase 50 Hz or 60 Hz systems. Its most notable feature is the self-gripping split-core design, which allows for instant and secure attachment around active conductors. Being UL listed and powered by induction from the line voltage, it is the ideal tool for energy audits, load management, and monitoring industrial or commercial electrical installations.

Key Features

• Non-Invasive Installation: The split-core design allows the sensor to "clamp" around the wire without needing to disconnect the load or cut the power.
• Certified Safety: UL listed, ensuring compliance with strict international electrical safety standards.
• Self-Powered: The power required for the sensor's operation is induced directly from the line being measured, eliminating the need for external batteries.
• Wide Compatibility: Seamlessly integrates with HOBO U12, UX120 data loggers and ZW wireless nodes.
• Versatile Operation: Optimized for sine waves and load power factors ranging from 0.5 to 1.0, whether leading or lagging.

• Specifications
• In the Box
• Required Items
• Optional Items

• Brand	Onset / HOBO
  Model	CTV-C
  Measurement Range	10 to 100 Amps AC
  Sensor Type	Split-core
  Input Frequency	50 Hz or 60 Hz (Sine wave)
  Phase	Single-phase
  Power Factor	0.5 to 1.0 (Lead or Lag)
  Certifications	UL Listed
  Weight	1.5 lb (680 g)

• • 1x CTV-C Split-Core AC Current Sensor (10-100A)
• • Compatible Data Logger (HOBO U12, UX120, or ZW Series)
  • External input cable (if required by the specific logger model)
• • HOBOware Software for data analysis
  • Additional current sensors for different ranges (CTV-A, CTV-B, CTV-D)

EO20260422

Ver todos los detalles del producto »

Acopladores de inicio para registradores de datos

Request Quote

Ver todos los detalles del producto »

Registrador de datos de inicio para dióxido de carbono, temperatura y humedad relativa

Request Quote

Ver todos los detalles del producto »

Registrador de datos de inicio para termopares de un canal HOBO UX100

Request Quote

Onset HOBO UX100-014M Thermocouple Data Logger

Monitor extreme temperatures with professional precision using this compact single-channel logger, ideal for industrial applications, laboratories, and scientific research.

The HOBO UX100-014M is a high-performance data logger designed to measure and record temperatures in a wide range of applications using external thermocouples. This device stands out for its versatility, supporting J, K, T, E, R, S, B, or N type thermocouples, allowing it to be used in everything from cryogenic processes to high-temperature ovens. Its integrated LCD screen makes it easy to view real-time readings, memory status, and battery levels. With USB connectivity and HOBOware software, setup and data analysis are fast and efficient, ensuring data integrity in critical environments.

Key Features

• Sensor Versatility: Compatible with multiple thermocouple types to cover extremely wide temperature ranges.
• Real-Time LCD Display: Allows you to check readings and operational status without needing to connect the device to a computer.
• High Memory Capacity: Stores thousands of measurements, ensuring detailed records over long periods of time.
• Compact and Durable Design: Built with high-strength plastic and featuring a screw mount for fixed and secure installation.
• Alarm Management: On-screen visual alarm function that alerts you when preset temperature limits are exceeded.
• Professional Software: Compatible with HOBOware for fast data downloads and detailed graphical analysis.

• Specifications
• In the Box
• Required Items
• Optional Items

• Brand	Onset / HOBO
  Model	UX100-014M
  Connector Type	Screw Terminal (Screw Mount)
  Number of Channels	1 (One thermocouple channel)
  Number of Contacts	2
  Number of Poles	2
  Material	High-resistance plastic
  Interface	USB 2.0
  Weight	0.1 lb (45 g)

• • 1x HOBO UX100-014M Data Logger
  • 1x USB Cable for PC connection
• • Thermocouple sensor (Type J, K, T, E, R, S, B, or N depending on application)
  • HOBOware Software (Available as a free download)
• • Protective carrying case
  • NIST Calibration Certificate
  • Additional mounting brackets

EO20260422

Ver todos los detalles del producto »

Registrador de datos Onset para termopares de cuatro canales HOBO UX120

$ 375.00 USD

HOBO® UX120 Thermocouple Data Logger Four Channels

4-channel temperature data logger with LCD display, precise measurement, and large data storage capacity. Compatible with J, K, T, E, R, S, B, and N probes for industrial and laboratory applications.

The HOBO UX120 Thermocouple Data Logger is a four-channel LCD data logger designed to measure and record temperature across a wide range of monitoring applications. It can accept up to four thermocouple probes of types J, K, T, E, R, S, B, or N.

In addition to accepting four thermocouple probes, the logger includes an internal temperature sensor to record ambient temperature, further expanding its range of applications.

Onset also offers a single-channel thermocouple data logger, the HOBO UX100-014M.

Key Features

• Easy-to-read LCD display confirms logger operation and battery status.
• Near real-time readings of current temperatures, along with minimum, maximum, average, and standard deviation statistics.
• On-screen alarms notify when temperatures exceed high or low limits.
• Large memory capacity capable of storing up to 1.6 million measurements.
• Start, stop, and reset buttons.
• User-upgradeable firmware.
• Optional protective enclosure for outdoor use.
• Compatible with HOBOware and HOBOware Pro software for setup, graphing, and data analysis.

Environment: indoor.

Supported measurements: temperature.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Operating Range (Temperature Sensor)	-20° to 70°C (-4° to 158°F)
  Accuracy (Temperature Sensor)	0.21 °C from 0 ° to 50 °C (± 0.38 °F from 32 ° to 122 °F)
  Resolution (Temperature Sensor)	0.024 °C at 25 °C (0.04 °F at 77 °F)
  Stability (Drift)	<0.1 °C (0.18 °F) per year
  Operating Range (Logger)	-20 ° to 70 °C (-4 ° to 158 °F), 0 to 95% RH (non-condensing); logger accuracy from 0 ° to 50 °C (32 ° to 122 °F)
  Reading Range (Logger)	0 ° to 50 °C (32 ° to 122 °F) per USB specification
  Logging Rate	1 second to 18 hours, 12 minutes, 15 seconds
  Logging Modes	Normal, burst, or statistical
  Battery	Two 1.5 V AAA alkaline batteries
  Memory	4 MB (1.6 million measurements, maximum)
  LCD	Visible from 0 ° to 50 °C; may respond slowly or go blank outside this range
  Memory Modes	Wrap when full or stop when full
  Dimensions	10.8 x 5.41 x 2.54 cm
  Weight	107.5 g
  Environmental Rating	IP50
  CE Marking	Complies with all relevant EU directives

• • 1x HOBO® UX120 Thermocouple Data Logger Four Channels
  • 1x Command™ Strip
  • 2x 1.5 V AAA alkaline batteries
  • 1x Hook-and-loop strap
  • 1x Hook-and-loop strap
• • Thermocouples for HOBO® Data Logger
  • 1x HOBOware Pro software CD or USB (USB cable included)
  • 1x HOBOware Pro software – Mac/Win (download only)
  • 1x USB cable
  • 1x Protective case for Thermocouple Data Logger
• • 1x Certificate of Conformity
  • 1x NIST-Traceable Certification Setup Fee
  • 1x Pelican Case
  • 1x Thermocouples for HOBO Data Logger
• • User Manual (English)
  • Technical Specifications (English)

Ver todos los detalles del producto »

Registrador de datos de inicio HOBO Temperatura y humedad relativa UX100

Request Quote

Ver todos los detalles del producto »

Registrador de datos de inicio Temp Water TidbiT v2

Request Quote

Ver todos los detalles del producto »

Cable de lectura directa Onset

Request Quote

Ver todos los detalles del producto »

Sensor inteligente de humedad del suelo Onset EC-5

$ 160.00 USD

Ver todos los detalles del producto »

Registrador de datos de nivel de agua dulce Onset HOBO U20

Request Quote

Ver todos los detalles del producto »

Microestaciones registradoras de datos HOBO Onset

Request Quote

HOBO Micro Station Data Loggers

Multichannel Data Logging Solution for Microclimates

Robust and compact, the redesigned HOBO USB Micro Station is a weather-resistant data logger for multichannel microclimate monitoring. This battery-powered station supports up to five plug-and-play smart sensors and features a hinged door for quick and easy sensor installation. The Micro Station comes with a built-in USB port for fast and efficient data readout to a computer and an integrated mounting tab for easy installation.

Features

• Compact size for easy deployment.
• IP66 weatherproof housing for harsh environments.
• Direct USB download—no adapter cable required.
• Includes five smart sensor inputs.
• Hinged door and integrated mounting tabs.
• Operates up to one year with four standard AA batteries.
• Compatible with HOBOware and HOBOware Pro software for logger setup, graphing, and analysis.

What environments does this station operate in?

Indoor and outdoor environments.

What measurements does this station support?

4-20 mA, Amp Hour (Ah), barometric pressure, DC voltage, kilowatt hours (kWh), leaf wetness, light intensity, power factor (PF), pulse input, rain, relative humidity, soil moisture, temperature, reactive volt-amperes, reactive volt-amp hours, volt-amperes (VA), water flow, watt-hours (Wh), watts (W), and wind.

• Specifications
• What's in the Box
• Required Items
• Optional Items
• Documents

• Features	Logger
  Operating Range	-20 ° to 50 °C (-4 ° to 122 °F) with alkaline batteries -40 to 70 °C (-40 to 158 °F) with lithium batteries
  Smart Sensor Connectors	5
  mart Sensor Data Channels	Maximum of 15 (some smart sensors use more than one data channel; see sensor manual for details)
  Smart Sensor Network Cable Length	100 m maximum(328 ft maximum)
  Logging Interval	1 second to 18 hours
  Start Modes	Immediate, at interval, push button, or delayed start
  Memory Modes	Stop when full or wrap when full
  Memory	512 KB non-volatile flash data storage
  Accuracy	0 to 2 seconds for the first data point and ±5 seconds per week at 25 °C (77 °F)
  Battery Type	Four AA 1.5 V alkaline batteries for operating conditions of -20° to 50°C (Four AA 1.5 V alkaline batteries for operating conditions of -4° to 122°F) Four AA 1.5 V lithium batteries for operating conditions of -40 to 70°C (Four AA 1.5 V lithium batteries for operating conditions of -40 to 158°F)
  Battery Life	1 year, typical use (up to five sensors with 1 minute or greater logging interval)
  Communication Type	USB 2.0 interface
  Full Memory Download Time	4 minutes
  Enclosure Access	Hinged door secured with a latch and eyelet for user-supplied padlock
  Materials	Outer enclosure: Polycarbonate/PBT blend with stainless steel hinge pins; Gasket: Silicone foam; Cable channel: EPDM rubber
  Dimensions	17.04 x 11.94 x 4.47 cm
  Weight	414 g
  Environmental Rating	IP50
  CE	CE marking identifies this product as complying with all relevant directives in the European Union (EU)

• • HOBO Micro Station Data Logger (1)
  • Four 1.5V AA alkaline batteries (4)
  • Rubber plugs
  • Grease pack
  • Screws and washers
  • Cable ties
• Software

  • HOBOware Pro software CD or USB drive (USB cable included).
  • HOBOware Pro software - Mac/Win (download only).
• Accessories
  • Lithium batteries.
  • Smart Sensor Consolidator Box Adapter.
  • Cable Caddy.
  • Pelican Case.
  • USB cable.
  • Compliance Certification.
  • Grounding Cable for H21-USB Cable.
  • Grounding Kit.
  Tripod Parts, Kits, and Masts

  • 3 m Mast.
  • 1.5 m Mast.
  • 3 m HWS Tripod Tower with Mast.
  • 3 m Tripod Kit for HOBO Weather Station.
  • 2 m HWS Tripod Tower with Mast.
  • U-Bolts.
  Communications
  • Micro Station Adapter Cable.
  • HOBO U-Shuttle.
  • HOBO® U30 Shuttle.
  • USB Interface Cable(s).
  • PC Interface Cable.
  Maintenance
  • Lithium batteries.
  • Replacement Desiccant Pack for HOBO Micro Station.
  • Dome Plugs for Accessing Serial Communication Port Replacement.
  • Replacement O-Ring for 85-DOMEPLUG.
  • Replacement O-Ring for 85-DOMEPLUG-1.
• • Installation Manual (EN)
  • Manual (FR)

Ver todos los detalles del producto »

Estación HOBO MicroRX de inicio

Request Quote

Una solución celular robusta, fácil de implementar y de bajo costo para monitoreo de campo confiable a largo plazo

Entradas para hasta cinco sensores plug-and-play. Acceso a los datos a través de la plataforma en la nube HOBOlink.

Elementos opcionales Los sensores externos se deben comprar por separado. Requiere un plan de datos HOBOlink, que debe renovarse anualmente. Obtenga más información sobre HOBOlink.

Una solución celular compacta, robusta, fácil de implementar y de bajo costo para monitoreo de campo confiable a largo plazo. Con dos opciones de energía disponibles (un panel solar para implementaciones extendidas o baterías reemplazables por el usuario para un montaje flexible en ubicaciones cubiertas o protegidas), esta estación de monitoreo incluye entradas para hasta cinco de los sensores plug-and-play de grado de investigación de Onset. (Los sensores se deben comprar por separado).

Las alarmas configurables del lado de la estación activan notificaciones inmediatas de condiciones críticas, y la plataforma en la nube HOBOlink de Onset facilita la visualización, el acceso y el intercambio de datos. Esta estación también se puede pedir con una entrada de sensor de nivel de agua adicional con conversión de caudal integrada.

Características sobresalientes

• Tamaño compacto para una fácil implementación
• Gabinete robusto, resistente a la intemperie IP66/NEMA 4X
• Dos opciones de energía:
• Panel solar integrado de 1,7 W con batería recargable
• Se pueden agregar paneles solares externos de 5 W y 15 W a MicroRX Station (RX2102), MicroRX Water Level Station (RX2104) o MicroRX Station para HOBOnet (RX2106)
• Baterías de litio AA reemplazables por el usuario
• Entradas para cinco sensores plug-and-play
• Opción para sensores inalámbricos usando HOBOnet (solo RX2106)
• Entrada de sensor de nivel de agua opcional incluida en la estación de nivel de agua MicroRX, con batería (RX2103) y la estación de nivel de agua MicroRX, con energía solar (RX2104)
• La pantalla LCD integrada confirma la configuración y el funcionamiento correctos
• Pestañas de montaje integradas para usar con tornillos, bridas o pernos en U
• Alarmas del lado de la estación, incluido el flujo de agua y la lluvia acumulada
• Tarifas de conexión de hasta 10 minutos a través de planes de datos móviles 4G
• Monitoreo basado en la nube y acceso a datos a través de HOBOlink

• Especificaciones
• En el cuadro
• Objetos requeridos
• Elementos opcionales
• Documentos

• • Especificaciones técnicas (inglés)
• • Estación MicroRX HOBO RX2100
  • Paquete de grasa
  • bridas para cables
  • tornillos y arandelas
  • Baterías
  • Manual
• • Software HOBOlink
  • Sensor
• • Software
  • Sensor
  • Accesorio
• • Especificaciones técnicas (inglés)

EO2023803

Ver todos los detalles del producto »

Estación de nivel de agua Onset HOBO MicroRX

Request Quote

Solución de monitoreo de nivel de agua remota y celular galardonada

para sitios de represas, aguas pluviales, aguas de inundación, riego, aplicaciones hidrológicas y ambientales

Elementos opcionales El producto necesita un sensor de nivel. Requiere un plan de datos HOBOlink, que debe renovarse anualmente. Obtenga más información sobre HOBOlink. No compatible con sensores inalámbricos HOBOnet.

Una galardonada solución celular de monitoreo remoto del nivel del agua para aplicaciones de aguas pluviales, inundaciones, irrigación, hidrológicas y ambientales. Las fórmulas de flujo de agua preprogramadas para vertederos, canales y una tabla de descarga por etapas dan como resultado una configuración fácil e intuitiva.

Los cálculos de caudal de agua y lluvia acumulada, que se realizan directamente en la estación en el momento de la medición, activan notificaciones inmediatas de las condiciones críticas del nivel del agua.

Esta estación compacta y duradera, junto con el sensor de nivel de agua sin ventilación, brinda un monitoreo confiable, incluso cuando se implementa en condiciones adversas. El panel solar integrado opcional o la energía de la batería, con una amplia gama de sensores inteligentes plug-and-play, admite un monitoreo ambiental flexible.

Características sobresalientes

• Las alarmas del lado de la estación para el flujo de agua y la precipitación acumulada se activan en el momento de la medición
• Sensor de nivel de agua de cerámica sin ventilación con una selección de cuatro rangos
• Cables de sensor de nivel de agua reforzados con Kevlar intercambiables
• Sensor de presión barométrica integrado
• Caja compacta IP66/NEMA 4X
• La pantalla LCD integrada confirma la configuración y el funcionamiento correctos
• Dos opciones de energía:
• Panel solar integrado de 1,7 W con batería recargable
• Se pueden agregar paneles solares externos de 5 W y 15 W (solo RX2104)
• Baterías de litio AA reemplazables por el usuario
• Entradas para cinco sensores plug-and-play
• Tarifas de conexiones de hasta 10 minutos a través de planes de datos móviles 4G
• Monitoreo basado en la nube y acceso a datos a través de HOBOlink
• Disponible con extremos de sensor de acero inoxidable o titanio
• Certificado de calibración rastreable NIST de 3 puntos incluido para el sensor de presión de agua

• Especificaciones
• En el cuadro
• Objetos requeridos
• Elementos opcionales
• Documentos

• • Especificaciones técnicas (inglés)
• • Estación MicroRX HOBO RX2100
  • Paquete de grasa
  • bridas para cables
  • tornillos y arandelas
  • Baterías
  • Manual
• • Software HOBOlink
  • Sensor
• • Sensor
  • Accesorio
• • Manual de usuario (inglés)
  • Especificaciones técnicas (inglés)

EO2023903

Ver todos los detalles del producto »

Onset HOBO MX2201 Pendant Wireless Temperature Data Logger ²⁶

$ 85.00 USD

HOBO Pendant MX Water Temperature Data Logger con Conectividad Bluetooth

Registra temperatura con precisión en agua, suelo y ambientes naturales con acceso inalámbrico directo desde tu dispositivo móvil o computadora. Un registrador compacto, resistente y diseñado para monitoreo ambiental confiable en campo.

El HOBO Pendant MX Water Temperature Data Logger es un registrador de temperatura impermeable diseñado para mediciones precisas en ambientes naturales como ríos, lagos, océanos y suelos. Gracias a su conectividad Bluetooth, permite configurar el dispositivo y descargar los datos de forma inalámbrica directamente desde un dispositivo móvil o una computadora con la aplicación gratuita HOBOconnect.

Este registrador compacto y robusto está diseñado para soportar condiciones ambientales exigentes. Su carcasa impermeable permite su uso en entornos acuáticos hasta 30 metros de profundidad, lo que lo convierte en una herramienta ideal para investigaciones ambientales, monitoreo hidrológico y estudios de campo.

El dispositivo puede almacenar hasta 96.000 mediciones de temperatura, lo que facilita la recopilación de datos a largo plazo. Además, los usuarios pueden ampliar las capacidades de gestión de datos mediante los planes MX Data Plan para integrarlo con la plataforma de software LI-COR Cloud y acceder a herramientas avanzadas de monitoreo remoto.

Características Destacadas

• Configuración y descarga inalámbrica mediante tecnología Bluetooth.
• Memoria interna capaz de almacenar hasta 96000 mediciones.
• Carcasa impermeable diseñada para operar hasta 30 metros de profundidad.
• Batería reemplazable por el usuario para mayor vida útil.
• Diseño compacto y resistente ideal para monitoreo ambiental.
• Pestañas de montaje integradas para instalación rápida.
• Indicador LED que alerta cuando la temperatura supera el umbral configurado.
• Compatible con la aplicación gratuita HOBOconnect.
• Precisión de medición de ±0.5 °C.

• Especificaciones
• En la Caja
• Artículos Opcionales
• Documentos

• Tipo de Dispositivo	Registrador de Temperatura con Bluetooth
  Aplicación	Monitoreo de Temperatura en Agua, Aire y Suelo
  Rango de Temperatura en Aire	-20 a 70 °C (-4 a 158 °F)
  Rango de Temperatura en Agua	-20 a 50 °C (-4 a 122 °F)
  Precisión	±0.5 °C
  Resolución	0.04 °C
  Deriva	<0.1 °C por Año
  Tiempo de Respuesta en Aire	17 Minutos Típicos al 90 % en Aire en Movimiento de 1 m/s
  Tiempo de Respuesta en Agua	7 Minutos Típicos al 90 % en Agua Agitada
  Memoria	96000 Mediciones
  Conectividad	Bluetooth
  Profundidad Máxima	30 m (100 ft)
  Batería	Reemplazable por el Usuario
  Compatibilidad de Software	Aplicación HOBOconnect para Dispositivos Móviles y Windows

• • 1x Registrador de Temperatura HOBO Pendant MX.
  • 1x Soporte de Montaje HOBO Pendant Mounting Boot.
• • MX Gateway MXGTW1.
  • Boot de Montaje Adicional BOOT-MX2201-2202.
  • Kit de Certificación de Temperatura NIST.
  • O-Ring de Reemplazo MX2201-02-ORING (Paquete de 5).
  • Plan Anual LI-COR Cloud MX-Speed.
  • Plan Anual LI-COR Cloud MX-Data.
  • Mochila HOBO North Face Groundwork ME-BP.
• • Manual de Usuario (Inglés).
  • Documentación de Certificación NIST Opcional.

Ver todos los detalles del producto »

Estación base USB Onset HOBO Optic

$ 179.25 USD

La estación base Universal Optic USB y los acopladores se utilizan para descargar datos de cualquier registrador de datos HOBO® con una interfaz Optic USB. La estación base Optic USB resistente a salpicaduras se conecta a su computadora a través de USB, mientras se conecta al registrador de datos a través de un acoplador apropiado. Esto es compatible con las series HOBO UA, U20, U22, U23, UTBI, U24 y U26. ( Descargar Manual de Usuario ).

NOTA: Los acopladores para todos los registradores de datos compatibles se incluyen con el BASE-U-4. Se incluyen acopladores para compatibilidad con seis de los tipos de registradores de datos Onset más populares, incluidos: colgantes UA, registradores de datos de nivel de agua U20, U22 Water Temp Pro v2, UTBI TidbiT, U24 Conductivity y registradores de datos U23.

• Descargue datos de cualquier registrador de datos HOBO® con una interfaz USB óptica.
• Los acopladores están incluidos.
• Longitud del cable 183 cm (6 pies).
• Descarga el registrador completo de 64K en 30 segundos.

• Especificaciones
• En el cuadro
• Objetos requeridos
• Elementos opcionales

• • Rango de temperaturas de funcionamiento: 0 a 50 °C (32 a 122 °F)
  • Longitud del cable: 183 cm (6 pies)
  • Tasa de descarga: descarga el registrador completo de 64K en 30 segundos
• • estación base (1)
  • Cable USB (1)
  • Acopladores (5)
• • Registrador de datos. Artículos compatibles


  Registradores de datos USB: solo sensores internos


  - RG3: Registrador de datos de pluviómetro


  - RG3-M: registrador de datos de pluviómetro (métrico)


  - U20-001-01: Registrador de datos de nivel de agua de 30 pies de profundidad


  - U20-001-01-Ti: registrador de datos de nivel de agua de titanio de 30 pies de profundidad


  - U20-001-02: Registrador de datos de nivel de agua dulce de 100 pies de profundidad


  - U20-001-02-Ti: registrador de datos de nivel de agua de 100 pies de profundidad


  - Registrador de datos de nivel de agua de profundidad U20-001-03250-Foot


  - Registrador de datos de nivel de agua de profundidad U20-001-03-Ti250-Foot


  - Registrador de datos de nivel de agua dulce U20-001-0413-Foot


  - Registrador de datos de nivel de agua de titanio de profundidad U20-001-04-Ti13-Foot


  - Registrador de datos de nivel de agua U20L-01 (30 pies)


  - Registrador de datos de nivel de agua U20L-02 (100 pies)


  - Registrador de datos de nivel de agua U20L-04 (13 pies)


  - Registrador de datos U22-001Water Temperature Pro v2


  - Registrador de datos de temperatura/humedad relativa U23-001U23 Pro v2


  - Registrador de datos de conductividad de agua dulce U24-001


  - Registrador de datos de conductividad/salinidad de agua salada U24-002-CSalt


  - Registrador de datos de oxígeno disuelto U26-001


  - UA-001-08: Registrador de datos de alarma/temperatura de 8K Pendant® (impermeable)


  - UA-001-64: Registrador de datos de temperatura/alarma de 64K Pendant® (impermeable)


  - UA-002-08: Registrador de datos de temperatura/luz 8K Pendant®


  - UA-002-64: Registrador de datos Pendant® de temperatura/luz 64K


  - UA-003-64: Registrador de datos de eventos Pendant®


  - UA-004-64: Registrador de datos Pendant® G


  - UTBI-001: Registrador de datos de temperatura del agua TidbiT v2



  Registradores de datos USB - con sensor(es) externo(s)


  - U23-002: Registrador de datos de temperatura/humedad relativa externa U23 Pro v2


  - U23-003: 2 registradores de datos de temperatura externa


  - U23-004: Registrador de datos de temperatura externa U23 Pro v2
• • Ninguno

Ver todos los detalles del producto »

Registrador de datos de eventos colgante HOBO Onset para lluvia

Request Quote

HOBO Pendant Event Data Logger for Rainfall

Submersible HOBO Temperature and Light Data Logger for Efficient Monitoring

HOBO data loggers require HOBOware software (USB interface cable included with CD) and a communication device. See compatible items below.

Records up to 160 inches of rain (RG3) or 3200 mm (RG3-M) at rates up to 12.7 cm (5 inches) per hour. The rainfall data logger system is battery-powered and includes a HOBO Pendant Event Data Logger (UA-003-64) with a rain collector. Easily records precipitation, time, and duration data, as well as temperature when used with an optional solar radiation shield (RS1 Solar Radiation Shield, or M-RSA). A station base or shuttle is required to collect the data.

Key Features:

• High-quality rain collector includes a HOBO Pendant Event data logger. A station base or shuttle is required.
• Date and time are stored for each drop—providing the necessary details to determine rainfall rates and duration.
• Reliable, field-tested rain collector.
• Compatible with HOBOware and HOBOware Pro software for logger configuration, graphing, and analysis.
• Also records temperature when used with a solar radiation shield (optional).

In which environment does this data logger work?

This data logger works in an outdoor environment.

Which measurements does this data logger support?

The RG3 and RG3-M devices support the following measurement: Precipitation.

• Specifications
• In the Box
• Required Items
• Optional Items

• Features	Rain Collector
  Maximum Precipitation Rate	12.7 cm
  Accuracy	± 1.0% (up to 1 inch/hour for RG3 or 20 mm/hour for RG3-M)
  Resolution	0.0254
  Calibration	0.2 mm
  Operating Range	0 ° to + 50 °C (+32 ° to +122 °F)
  Storage Temperature Range	-20 ° to + 70 °C (-4 ° to +158 °F)
  Environmental Rating	Waterproof
  Housing	15.24 cm aluminum collector
  Dimensions	25.72 cm height x 15.24 cm diameter - 15.39 cm receiving aperture
  Weight	1.2 kg
  Features	Logger
  Time Stamp Resolution	1.0 seconds
  Accuracy	± 1 minute per month at 25°C (77°F), see Plot B on page 10.
  Operating Range	-20 ° to 70 °C (-4 ° to 158 °F)
  Environmental Rating (for the logger used outside the rain collector)	Approved for NEMA 6 and IP67; Suitable for outdoor deployment
  Battery	Lithium battery
  Memory	64K bytes - 16K to 23K events when only rain is recorded
  Materials	Polypropylene case; stainless steel screws

• • HOBO Rain Gauge Data Logger (1)
  • tipping Rain Collector
  • Hose Clamps (2)
  • Screws (3)
• Software

  • HOBOware Pro Software CD or USB Drive (USB cable included)
  • HOBOware Pro Software - Mac/Win (Download only)
  Communications (Choose a Station)

  • Onset USB Optical Base Station for HOBO Pendant®.
  • Onset USB Optical Base Station for HOBO.
  • Onset Waterproof Transport Station for HOBO.
  • USB Cable.
• Accessories

  • Solar Radiation Shields.
  • NIST Temperature Point Certification.
  • NIST Traceable Certification Installation Rate.
  • Compliance Certification.
  • Pelican Case.
  Maintenance

  • Replacement Batteries (Pack of 5).
  • Replacement Pendant® Housing Kit.
  • Onset Waterproof Transport Station for HOBO.

Ver todos los detalles del producto »

Registradores de datos colgantes de temperatura/luz HOBO Onset

Request Quote

Ver todos los detalles del producto »

Registrador de datos de pluviómetro HOBO Onset

Request Quote

Ver todos los detalles del producto »

Sensores de humedad del suelo HOBO Onset

Request Quote

Ver todos los detalles del producto »

Protector de Radiación Solar Onset HOBO

$ 125.00 USD

Onset HOBO Solar Radiation Protectors

Versatile mounting solutions for secure installation of HOBO data loggers

The HOBO RS1 mounting brackets (Unassembled) and M-RSA (Pre-assembled) are designed to provide secure and reliable installation of your HOBO data loggers in various applications. The RS1 bracket allows for easy mounting on flat or irregular surfaces, while the M-RSA is optimized for installation on masts, providing stability even in demanding environments. Additionally, the HOBO RS3-B solar radiation shield is designed to enhance the accuracy of temperature and relative humidity measurements in areas exposed to direct or reflected solar radiation. It is compatible with tripods, masts, or flat surfaces.

The shield is recommended for accuracy in measuring temperature and relative humidity in areas directly exposed to or reflected by solar radiation. It can be mounted on tripods, masts, or flat vertical surfaces. It is ideal for use with data loggers such as HOBO Pendant and U-Series data loggers.

Note: Please note that if you are using a U-23 data logger, it may be necessary to purchase the U-23 Clamp Kit.

Features:

• RS1: Versatile support for mounting on flat or irregular surfaces
• M-RSA: Specialized support for installation on masts or poles
• RS3-B: Solar shield for data loggers, improves temperature and humidity accuracy
• Durable, weather-resistant material
• Easy to install with included accessories
• Compatible with a wide range of HOBO data loggers

• Specifications
• In the Box
• Documents

• RS1
  Height	152 mm (6.0 inches); 165 mm (6.5 inches) with bracket
  Width	210 mm (8.3 inches)
  Depth	187 mm (7.4 inches); bracket protrudes an additional 44 mm (1.8 inches) from shield
  Mounting	Includes 1.5" U-bolts for mounting on masts, or mount on a flat surface with user-supplied screws




  M-RSA
  Height	152 mm (6.0 inches); 165 mm (6.5 inches) with bracket
  Width	210 mm (8.3 inches)
  Depth	187 mm (7.4 inches); bracket protrudes an additional 44 mm (1.8 inches) from shield
  Mounting	Includes 1-5/8" U-bolts for mounting on masts, or mount on a flat surface with user-supplied screws




  RS3-B
  Height	280 mm (11.0 inches)
  Width	220 mm (8.7 inches)
  Depth	190 mm (7.5 inches)
  Weight	0.68 kg
  Mounting	Compatible with 1.25" to 2.1" masts or flat surfaces

• • Installation accessories
  • User manual
• • User manual for RS1 reference (English)
  • User manual for M-RSA reference (English)
  • User manual for RS3-B reference (English)

Ver todos los detalles del producto »

Registradores de datos de temperatura / HR Bluetooth HOBO de inicio

Request Quote

477 / 5.000 Resultados de traducción El HOBO MX2301 es un registrador de datos resistente a la intemperie con sensores de temperatura y humedad relativa incorporados. El HOBO MX2302 es un registrador de datos resistente a la intemperie con sensores externos de temperatura y humedad relativa.

Aprovechando Bluetooth Low Energy, el registrador permite una configuración rápida y sencilla y la descarga de datos directamente desde su dispositivo móvil, y proporciona mediciones de alta precisión en entornos exteriores hostiles.

Características destacadas:

• Cómoda configuración inalámbrica y descarga a través de Bluetooth Low Energy (alcance de 100 pies).
• Recupere datos en lugares de difícil acceso.
• Las alarmas visuales lo alertan sobre condiciones fuera de rango.
• Carcasa compacta resistente a la intemperie con montaje incorporado.
• Vea los datos actuales en tiempo real con la aplicación gratuita HOBOmobile de Onset.
• Comparta datos descargados fácilmente desde su dispositivo móvil.
• Precisión: +/-0.2C° y +/-2.5% HR.

¿En qué entorno funciona este registrador de datos?

entorno exterior.

¿Qué medidas admite este registrador de datos?

Humedad relativa y temperatura.

• especificaciones
• En el cuadro
• Objetos requeridos
• Elementos opcionales

• Característica	Sensor de temperatura
  Rango de operación	sensores internos MX2301A y MX2305: -40 a 70 °C (-40 a 158 °F). Sensor de temperatura externo MX2302A: -40 a 70 °C (-40 a 158 °F). sensores externos MX2303 y MX2304: -40 a 100 °C (-40 a 212 °F), con punta y cable inmersión en agua dulce hasta 50 °C (122 °F) durante un año.
  Precisión	± 0,25 °C de -40 a 0 °C (± 0,45 de -40 a 32 °F). ± 0,2 °C de 0 a 70 °C (± 0,36 de 32 a 158 °F). ± 0,25 °C de 70 a 100 °C (± 0,45 de 158 a 212 °F), solo MX2303 y MX2304.
  Resolución	0,04 °C (0,072 °F).
  Deriva	0,01 °C (0,018 °F) por año.
  Característica	Sensor de Humedad Relativa (Solo MX2301A y MX2302A)
  Rango de operación	0 a 100% de HR, -40 a 70 °C (-40 a 158 °F); la exposición a condiciones más bajas a -20 °C (-4 °F) o por encima del 95 % del sensor de HR puede aumentar temporalmente el error máximo del sensor de HR en un 1 % adicional.
  Precisión	± 2,5% de 10% a 90% (típico) hasta un máximo de ± 3,5%, incluyendo histéresis a 25 °C (77 °F); por debajo del 10 % de HR y por encima del 90 % de HR ± 5 % típico. del sensor de HR en un 1% adicional.
  Resolucion	0.01%
  derivado	<1% por año.
  Memoria	128 KB (63.488 medidas, máximo).

• • Registrador de datos de temperatura/HR HOBO.
  • Tornillos.
  • Ataduras de cables.
• • Aplicación HOBOMobile (Gratis).
  • Teléfono celular o tableta compatible.
• • Accesorios

    • Escudos de radiación solar.
    • Certificación de punto de temperatura NIST.
    • Certificación del servicio de calibración inicial de humedad relativa del NIST.
    • Tarifa de instalación de certificación rastreable NIST.
    • Certificación de Cumplimiento.
    Mantenimiento

    • Baterías de Repuesto (Pack x 2 uds.)

(DR 20220809)

Ver todos los detalles del producto »

Registrador de datos de temperatura/HR de inicio HOBO

$ 129.00 USD

Ver todos los detalles del producto »

Registrador de datos de temperatura y humedad relativa HOBO de inicio Bluetooth

Request Quote

The Onset HOBO MX1101 Data Logger measures and wirelessly transmits temperature and relative humidity data to mobile devices via Bluetooth Low Energy (BLE) technology. The stand-alone wireless data logger, which operates with Onset’s free HOBOmobile® app for configuring and managing logger data, allows you to access data at any time from iOS or Android mobile devices within a 100-foot range and does not require any dedicated equipment beyond a mobile device to configure the logger or read data.

With Onset's free HOBOmobile® app, you can view data in graphs, check the operational status of loggers, set alarm notifications, and share data files.

Key Features:

• Wireless communication via Bluetooth Low Energy (BLE) technology.
• Easy to set up and download using the free HOBOmobile app.
• High and low visual and audible alarm thresholds.
• Stores 84,000 readings.
• Accuracy: +/- 0.2°C and +/- 2% RH.
• Find Me / locator function.
• Proprietary connectivity technology.

What environment does this data logger operate in?

Operates in an indoor environment.

What measurements does this data logger support?

Relative humidity and temperature.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Features	Temperature Sensor
  Operating Range	-20° to 70° C (-4° to 158° F)
  Accuracy	± 0.21 ° C from 0 ° to 50 ° C (± 0.38 ° F from 32 ° to 122 ° F)
  Resolution	0.024 ° C at 25 ° C (0.04 ° F at 77 ° F)
  Stability (drift)	<0.1 ° C (0.18 ° F) per year
  Features	HR Sensor *
  Operating Range	1% to 90%, non-condensing
  Accuracy	± 2.0% from 20% RH to 80% RH typical up to ± 4.5%, including hysteresis at 25 ° C (77 ° F); below 20% RH and above 80% RH ± 6% typical
  Resolution	0.01%
  Drift Stability	<1% per year typical
  Features	Response Time
  Temperature	7:30 minutes in moving air 1 m/s (2.2 mph)
  RH	20 seconds to 90% in 1 m/s (2.2 mph) airflow
  Features	Logger
  Radio Power	1 mW (0 dBm)
  Transmission Range	1 mW (0 dBm)
  Wireless Data Standard	Bluetooth Smart (Bluetooth Low Energy, Bluetooth 4.0)
  Logger Operating Range	-20 ° to 70 ° C (-4 ° to 158 ° F); 0 to 95% RH (non-condensing)
  Logging Rate	1 second to 18 hours
  Memory	84,000 measurements
  Power	3.6 V lithium battery (included)
  Dimensions	6.4 x 4.4 x 1.6 cm (2.5 x 1.7 x 0.6 in)
  Weight	113 grams (4 oz)
  Agency Approvals	CE, RoHS, WEEE

• • HOBO MX1101 Data Logger
  • 3.6 V Lithium Battery (installed)
  • Mounting Strap
  • Quick Start Guide
• • HOBOmobile® App (available for iOS and Android)
• • USB Adapter (for connecting with a PC or Mac)
  • Additional Mounting Options (if needed)
• • HOBO MX1101 User Manual
  • HOBO MX1101 Quick Start Guide

Ver todos los detalles del producto »

Registradores de datos de temperatura, humedad relativa y luz Onset HOBO U12

Request Quote

Ver todos los detalles del producto »

Registradores de datos de conductividad Onset HOBO U24

Request Quote

HOBO U24: Intelligent Water Quality Monitoring in Any Environment

All-in-one solution for accurate measurement of conductivity, salinity and temperature in aquatic environments

These high-precision conductivity data loggers are a cost-effective way to collect water quality data. The HOBO U24-001 data logger records both conductivity and temperature measurements in streams, lakes and other freshwater sources. This data logger is recommended for monitoring aquifers for saltwater intrusion and runoff from roads or agricultural land.

The HOBO U24-002-C is a cost-effective data logger for measuring salinity, conductivity and temperature in saltwater environments with relatively small changes in salinity (± 5,000 µS/cm), such as saltwater bays, or for detecting salinity events such as surges, storms or discharges. It can also be used to collect salinity data for salinity compensation of HOBO U26 dissolved oxygen data.

This open-to-its-sensor product simplifies cleaning and maintenance. The non-contact HOBO sensor minimizes measurement errors related to changes. In addition, the data loggers feature software-based shift compensation.

Key Features

• Non-contact sensor offers long life and fewer measurement shifts.
• Provides easy access to the sensor for cleaning and air bubbles.
• HOBOware Pro software allows start/end point calibration to compensate for any fouling and provides easy conversion to specific conductivity and salinity.
• Optical USB interface offers high-speed, reliable data download in humid environments.
• Compatible with the HOBO U-DTW-1 Waterproof Shuttle for easy and reliable data capture and transport.
• Delrin housing does not corrode with sea salt.
• Two user-selectable ranges provide measurements from 100 to 55,000 µS/cm for the Saltwater data logger.

In what environment does this data logger work?

It works in outdoor and underwater environments.

What measurements does this data logger support?

Supports conductivity/salinity and temperature.

Note: When monitoring salinity in waters with more than +/- 5,000 µS/cm variation, refer to the accuracy shown in Plot C in the product specifications to determine if the accuracy is acceptable for your needs. Monthly field calibration readings are generally required to achieve the best accuracy.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

Ver todos los detalles del producto »

Registrador de datos de oxígeno disuelto Onset HOBO U26-001

Request Quote

HOBO® U26 High-Precision Optical Dissolved Oxygen Datalogger

Accurately Measures Dissolved Oxygen And Temperature With A Durable Optical Sensor, Delivering Reliable Data For Scientific Monitoring And Field Research.

The HOBO® U26 Dissolved Oxygen datalogger records dissolved oxygen concentration and water temperature with high precision and reliability. It uses an optical sensor that ensures long-term stability and eliminates accuracy drift over time.

The free HOBOware® software, available for Windows and Mac, allows you to download, visualize, and configure all instrument parameters such as date and time. Communication with the computer is done through the universal optical USB base station BASE-U-4 or the U-DTW-1 shuttle (not included).

Designed for harsh aquatic environments, the datalogger features a compact and corrosion-resistant construction that ensures long-term durability. The included lithium battery provides an extended operational lifespan before replacement is needed.

Key Features

• High-Precision Optical Sensor That Prevents Long-Term Accuracy Drift.
• Storage Capacity Of 21,700 Records For Extended Monitoring Sessions.
• Free HOBOware Software For Data Visualization And Configuration On Windows And Mac.
• Corrosion-Resistant Construction Rated For Operation Down To 100 M Depth.
• Long-Life Lithium Battery With Approximately 3 Years Of Operation.
• Compact And Lightweight Design For Easy Field Deployment.

• Specifications
• In the Box
• Required Items
• Documents

• Memory Capacity	21,700 Records
  Dissolved Oxygen - Range	0 to 30 mg/L
  Dissolved Oxygen - Resolution	0.02 mg/L
  Dissolved Oxygen - Accuracy	±0.2 mg/L
  Temperature - Range	-5 °C to 40 °C
  Temperature - Resolution	0.02 °C
  Temperature - Accuracy	±0.2 °C
  Power Supply Voltage	3.6 VDC
  Battery Type	1 × 1/2 AA Lithium
  Battery Life	Approx. 3 Years
  Output Signal	Optical
  Operating Temperature	-5 °C to 40 °C
  Maximum Depth	100 m
  Material	High-Strength Plastic
  Dimensions	∅ 39.6 × 266.7 mm
  Weight	464 g

• • 1x HOBO® U26 Dissolved Oxygen Datalogger
  • 1x 1/2 AA Lithium Battery (Installed)
  • 1x Quick Start Guide
  • 1x HOBOware® Software Download Information
• • 1x BASE-U-4 Optical USB Base Station or U-DTW-1 Waterproof Shuttle (Not Included)
• • HOBOware® Software for Windows and Mac (Downloadable)
  • HOBO® U26 User Guide (Included with Device)

Ver todos los detalles del producto »

Estación transportadora impermeable HOBO Onset

Request Quote

Ver todos los detalles del producto »

Registrador de datos analógico de cuatro canales Onset HOBO® UX120

Request Quote

Ver todos los detalles del producto »

Sensor inteligente de luz fotosintética de inicio (PAR)

$ 220.00 USD

El sensor inteligente de luz fotosintética (PAR) está diseñado para medir la intensidad de la...

Ver todos los detalles del producto »

Pluviómetro de inicio (cable de 2 m) Sensores inteligentes

$ 446.50 USD

Este sensor inteligente de pluviómetro mide las precipitaciones con una intensidad de hasta cinco pulgadas...

Ver todos los detalles del producto »

Estación meteorológica remota Onset (Consola) HOBO RX3000

Request Quote

El HOBO RX3000, la estación de registro de datos remota más flexible de Onset, brinda...

Ver todos los detalles del producto »

Onset RX3000 Remote Monitoring Station for Indoor Environments with Real-Time Access

Request Quote

Total Environmental Control: HOBO RX3000 Station with Remote Access and Smart Sensors

Real-time remote access to site-specific indoor environmental data.

The RX3000 is HOBO’s most flexible remote data logging station, ideal for monitoring indoor conditions with remote access via the Internet. Its modular design allows for custom configurations using smart sensors and optional modules, all operating with a plug-and-play system and local viewing via an integrated LCD screen. It is a professional solution backed by the HOBOlink cloud platform, which requires an annually renewable RX data plan.

Features

• Compatible with a wide range of smart sensors
• Built-in LCD screen for viewing data and system status
• Remote access via HOBOlink (requires RX data plan)
• Alarm notifications via email or SMS
• Automatic data delivery scheduling
• Configurable via web browser or mobile device
• Optional modules: analog input, relay, water level sensor
• Simple plug-and-play operation

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Operating Range	-40°C to 60°C (-40°F to 140°F)
  Smart Sensor Connectors	10
  Maximum Sensor Cable Length	100 m (328 ft)
  Smart Sensor Channels	Up to 15
  Module Slots	2
  Logging Rate	1 second to 18 hours (model depends on RX variant)
  Time Accuracy	±8 seconds/month (0–40°C), ±30 seconds/month (-40–60°C)
  Power Supply	4V 10AHr sealed lead-acid rechargeable battery (requires external power: AC, solar, or 5–17V DC)
  Battery Life	Typically 3–5 years (-20°C to 40°C)
  Memory	32 MB, up to 2 million measurements
  Alarm Notification Latency	Logging interval + 2–4 minutes
  LCD Screen	Visible from 0°C to 50°C (may react slowly or go blank outside this range)
  Enclosure Material	Polycarbonate/PBT, silicone gaskets, brass inserts, EPDM cable channel
  Mounting	Mounts on 1.5 in (3.8 cm) mast or wall
  Environmental Rating	NEMA 4X weather-resistant
  FCC/IC Compliance	RX3002: FCC R68XPICOW / IC 3867A-XPICOW RX3003: FCC QIPEHS6 / IC 7830A-EHS6 RX3004: FCC QIPPLS62-W / IC 7830A-PLS62W
  Wireless Radio	RX3003: GSM/UMTS; RX3004: GSM/UMTS/LTE (multi-band)
  Antenna	RX3003: Penta band RX3004: 4G LTE

• • RX3000 Monitoring Station (1)
  • Integrated rechargeable battery (1)
  • User manual (1)
• • Active RX data plan (sold separately)
  • External power supply (AC-U30, SOLAR-xW panel, or 5–17V DC source with CABLE-RX-PWR)
• • Analog input module
  • Relay module
  • Water level sensor module
  • Compatible smart sensors (temperature, humidity, CO₂, etc.)
• • User Manual (English)
  • Developer Guide (English)

Ver todos los detalles del producto »

Sensores de temperatura inteligentes Onset de 12 bits

Request Quote

Ver todos los detalles del producto »

Sensor de presión barométrica inteligente Onset

$ 249.00 USD

El sensor inteligente de presión barométrica tiene un rango de medición de 660 mb a...

Ver todos los detalles del producto »

Sensor de humedad de hoja inteligente Onset

Request Quote

Monitor Leaf Moisture with Precision for Environmental and Agricultural Research

The Smart Leaf Wetness Sensor Provides Accurate and Stable Measurements for Research, Agriculture, and Environmental Monitoring Applications in Outdoor Environments without the Need for Additional Coatings.

The Smart Leaf Wetness Sensor is designed to provide reliable data on moisture presence across leaf surfaces in agricultural, environmental, and scientific research applications. Its advanced capacitive grid technology reduces sensitivity to surface residue, delivering more consistent and accurate measurements compared to traditional resistive-grid sensors.

The sensor arrives ready to use and does not require painting or additional coatings. It is also pre-conditioned to ensure long-term stability and consistency between sensors, making it ideal for continuous monitoring projects requiring dependable comparative data.

A 3 m cable and adjustable mounting bracket are included, allowing the sensor to be positioned at various angles to simulate the natural drying characteristics of the plants being studied. Its rugged design enables reliable operation in demanding outdoor environmental conditions.

Características Destacadas

• No painting or coating required.
• Capacitive grid technology less sensitive to surface residue.
• Pre-conditioned for consistent measurements and long-term stability.
• Includes a 3 m cable and adjustable mounting bracket.
• Designed for agricultural, environmental, and scientific applications.
• Compatible with multiple weather station data loggers.
• Allows simulation of real leaf drying conditions.
• Durable design for outdoor environments.
• Wide operating range for various environmental conditions.
• High accuracy and repeatability.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Model	Smart Leaf Wetness Sensor
  Measurement Range	0 (dry) to 100% (wet).
  Operating Range	-40 °C to 70 °C (-40 °F to 158 °F).
  Repeatability	± 5%.
  Resolution	0.59%.
  Stability	± 5% per year.
  Measurement Averaging Option	No.
  Sensor-to-Sensor Interchangeability	± 10% within the 10-90% range.
  Housing	No coating required.
  Sensor Type	Capacitive grid.
  Sensor Plate Dimensions	4.7 cm x 5.1 cm.
  Tube Dimensions	12.2 cm length x 1.8 cm diameter.
  Cable Length	3 m.
  Smart Sensor Network Cable Length	3 m.
  Weight	127 g.
  Mounting Bracket	20 cm length with adjustment between 0° and 90°.
  Number of Data Channels	1.
  Certification	CE marked in compliance with relevant European Union directives.
  Operating Environment	Outdoor.
  Supported Measurement	Leaf wetness.

• • 1x Smart Leaf Wetness Sensor.
• • USB Weather Station Data Logger U30.
  • USB Micro Station Data Logger.
  • RX3000 Remote Monitoring Station Data Logger.
  • USB Weather Station Starter Kit U30.
• • Weatherproof extension cable.
  • 2 m smart sensor extension cable.
  • 5 m smart sensor extension cable.
  • 10 m smart sensor extension cable.
  • 25 m smart sensor extension cable.
  • Certificate of compliance.
• • Smart Leaf Wetness Sensor User Manual (English).

Ver todos los detalles del producto »

Sensor de pluviómetro inteligente Onset

Request Quote

Ver todos los detalles del producto »

Sensores de temperatura/HR inteligentes Onset HOBO

$ 189.00 USD

Ver todos los detalles del producto »

Sensor inteligente de radiación solar de inicio (piranómetro de silicio)

$ 210.00 USD

Mida de manera efectiva los niveles de luz con este sensor de piranómetro de silicio....

Ver todos los detalles del producto »

Sonda de temperatura de inicio en acero

Request Quote

Ver todos los detalles del producto »

Onset Temperature Sensor for Air, Water & Soil

Request Quote

Self-Describing Air/Water/Soil Temperature Sensor

The self-describing temperature sensor for air, water, and soil is ideal for the HOBO MX1104 and MX1105 data loggers, offering automatic and easy configuration.

This temperature sensor is compatible with the HOBO MX1104 and MX1105 multichannel data loggers. It features integrated strain relief to secure the probe to the logger and self-describing technology to automatically communicate configuration information.

Key Features

• Self-Describing Technology: Quick and easy setup.
• Locking Connector: Ensures the sensor stays connected.
• Measurement Range: -40° to 100°C in air; -40° to 50°C in water.
• High Accuracy: ±0.15°C from 0° to 70°C.
• Various Cable Lengths: 0.3 m, 1.8 m, 5.1 m, and 15.2 m.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specification	Detail
  Measurement Range	-40° to 50°C in water; -40° to 100°C in air
  Accuracy	±0.15°C from 0° to 50°C (±0.27°F from 32° to 122°F)
  Resolution	0.002° at 25°C (0.003° at 77°F)
  Drift	<0.1°C (<0.2°F) per year
  Response Time in Air	Typical 2 minutes to 90% in air moving at 1 m/s (2.2 mph)
  Response Time in Water	Typical 30 seconds to 90%
  Operating Range	Probe tip and cable immersion in fresh water up to 50°C for 1 year
  Probe Material	Copper-coated sensor tip
  Probe Dimensions	5.1 x 33 mm (0.2 x 1.3 inches)
  Available Cable Lengths	0.3 m, 1.8 m, 5.1 m, 15.2 m

• • Air/Water/Soil Temperature Sensor
  • Cable of selected length (0.3 m, 1.8 m, 5.1 m, or 15.2 m)
  • Locking Connector
  • Manual
• • Bluetooth (BLE) Data Loggers
  • HOBO Temp/RH/Light/Ext-Analog Data Logger
  • MX1104
  • HOBO 4-Channel Analog Data Logger
• • Data Logger
• • Technical Specifications (English)

Ver todos los detalles del producto »

Sensores de temperatura de inicio para aire/agua/suelo

Request Quote

Ver todos los detalles del producto »

Termopares de inicio para registrador de datos HOBO®

$ 32.00 USD

Ver todos los detalles del producto »

Estuche protector Onset U2X para registradores de datos HOBO

Request Quote

Ver todos los detalles del producto »

Cable USB de inicio

Request Quote

Onset USB Cable

Reliable USB connectivity for HOBO weather stations

The USB Cable for HOBO weather stations is a reliable and durable solution for connecting your HOBO devices to a computer. This cable is specifically designed to ensure fast and stable data transmission between weather stations and monitoring software, offering flexibility for data download and device maintenance.

Key Features:

• High-strength cable length
• High-speed USB connection
• Compatible with HOBO weather stations
• Durable and resistant materials
• Easy to connect and use

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Cable length	1.8 meters
  Connector type	USB Type-A to Micro-B
  Compatibility	HOBO weather stations
  Transfer speed	High-speed USB 2.0

• • 1 USB Cable (1.8 meters)
• • None
• • None
• • None

Ver todos los detalles del producto »

Cable de interfaz USB de inicio

$ 10.00 USD

Ver todos los detalles del producto »
