Self-Describing Air/Water/Soil Temperature Sensor

The self-describing temperature sensor for air, water, and soil is ideal for the HOBO MX1104 and MX1105 data loggers, offering automatic and easy configuration.

This temperature sensor is compatible with the HOBO MX1104 and MX1105 multichannel data loggers. It features integrated strain relief to secure the probe to the logger and self-describing technology to automatically communicate configuration information.

Key Features

Self-Describing Technology: Quick and easy setup.

Locking Connector: Ensures the sensor stays connected.

Measurement Range: -40° to 100°C in air; -40° to 50°C in water.

High Accuracy: ±0.15°C from 0° to 70°C.

Various Cable Lengths: 0.3 m, 1.8 m, 5.1 m, and 15.2 m.

Specification	Detail
Measurement Range	-40° to 50°C in water; -40° to 100°C in air
Accuracy	±0.15°C from 0° to 50°C (±0.27°F from 32° to 122°F)
Resolution	0.002° at 25°C (0.003° at 77°F)
Drift	<0.1°C (<0.2°F) per year
Response Time in Air	Typical 2 minutes to 90% in air moving at 1 m/s (2.2 mph)
Response Time in Water	Typical 30 seconds to 90%
Operating Range	Probe tip and cable immersion in fresh water up to 50°C for 1 year
Probe Material	Copper-coated sensor tip
Probe Dimensions	5.1 x 33 mm (0.2 x 1.3 inches)
Available Cable Lengths	0.3 m, 1.8 m, 5.1 m, 15.2 m

Air/Water/Soil Temperature Sensor
Cable of selected length (0.3 m, 1.8 m, 5.1 m, or 15.2 m)
Locking Connector
Manual

Bluetooth (BLE) Data Loggers
HOBO Temp/RH/Light/Ext-Analog Data Logger
MX1104
HOBO 4-Channel Analog Data Logger

Data Logger

Technical Specifications (English)

Self-Describing 6-Foot Stainless Steel Temperature Sensor

For use with HOBO MX1104 and MX1105 Multi-Channel Data Loggers, this food-grade stainless steel temperature sensor features integrated strain relief to keep the probe securely connected to the logger. It also includes self-describing technology to automatically communicate configuration information to the logger, eliminating the need for extensive user programming or setup.

Features

Self-describing technology for quick and easy setup

Locking connector to ensure the sensor stays connected

Food-grade stainless steel temperature probe

Measurement range of -40° to 100°C (-40° to 212°F)

Accuracy of ±0.15°C from 0° to 70°C (±0.27°F from 32° to 158°F)

Available in 1.8 m (6 feet) length

Measurement Range	-40° to 100°C / -40° to 212°F
Accuracy	±0.15°C from 0° to 50°C (±0.27°F from 32° to 122°F), insert probe at least 5.08 cm (2 inches); see Chart A
Resolution	0.002° at 25°C / 0.003° at 77°F
Drift	<0.1°C (<0.2°F) per year
Response Time in Air	Typical 3 minutes to 90% in air moving at 1 m/s (2.2 mph)
Response Time in Agitated Water	Typical 15 seconds to 90%
Probe Diameter	3.2 mm ±0.25 mm / 0.12 inches ±0.01 inches
Probe Length	10.2 cm / 4 inches
Probe Housing	Food-grade stainless steel (#316 stainless steel) Note: The stainless steel probe is waterproof, but the cable is not intended for prolonged use in water or humid environments, especially those with temperatures above 30°C (86°F). For more details, contact Onset Computer Corporation or an authorized Onset distributor.
Cable Length	1.8 m / 6 feet
