SMART 3 Electronic Soil Laboratory - Complete Solution for Soil Analysis

Advanced portable equipment for precise soil nutrient analysis

Portable and electronic laboratories designed for landowners, consultants, and fertilizer specialists who need immediate and economical analyses without compromising precision. These units analyze fifteen soil factors, including critical macronutrients and micronutrients, using the SMART® 3 Colorimeter to obtain readings in ppm or lb/acre without the need for additional calculations. The SCL-12 model includes a pH meter and a dissolved salts meter, which allow quick and accurate measurements of pH and dissolved salt levels in soils and irrigation waters.

Simplified tests allow at least 20 analyses per soil nutrient, using easy-to-prepare soil extracts based on Mehlich I extraction. Additionally, the manual "A Study of Soil Science" is now available for download, offering a detailed reference and further guidance for performing analyses correctly and effectively. These features make the Electronic Soil Labs an invaluable tool for achieving precise and rapid soil analyses in the field.

Key Features

Advanced Technology: Colorimetric system for precise readings.

Portable and Robust: Easy to transport and durable for field or laboratory use.

Complete and Functional: Includes reagents, tools, and software for soil analysis.

Reliable Results: Quick readings with minimal sample preparation.

Multifunctionality: Compatible with various sample types and parameters.

Intuitive Display: User-friendly interface for ease of use.

Colorimeter Tests

Test Factor	Method	Range	# of Tests
Nitrate Nitrogen	Cadmium Reduction	0-300 lbs/acre	20
Nitrite Nitrogen	Diazotization	0-40 lbs/acre	20
Ammonia Nitrogen*	Nesslerization	0-200 lbs/acre	50
Phosphorus	Ascorbic Acid Reduction	0-99 lbs/acre	50
Potassium	Tetraphenyl-boron	0-500 lbs/acre	100
Sulfur	Barium Chloride	3-94 ppm	50
Copper	Diethyldi-thiocarbamate	0-30 ppm	100
Iron	Bipyridal	0-30 ppm	50
Manganese	Periodate	0-75 ppm	50
Zinc	Zincon	0-15 ppm	50

Direct Reading Titrator Tests

Test Factor	Range*	# of Tests
Calcium	0-4000 lbs/acre	50
Magnesium	0-2400 lbs/acre	50
Chlorides	0-1000 lbs/acre	50

TRACER pH & Conductivity PockeTesters

Test Factor	Range	Resolution	Accuracy
Conductivity	0 to 199.9 μS; 200 to 1999 μS; 2.00 to 19.99 mS	0.1 μS; 0.01 mS	±2% FS
pH	0.00 to 14.00 pH	0.01 pH	±0.01 pH

Unit Conversion Factors

Results can be measured using a choice of units, explained here. Parts per million (ppm), pounds/acre, and Kg/hectare units can be converted to each other using these values.

Area	Soil Depth	Soil Weight
1 acre	6-7 inches	2 million lb
1 hectare	15-18 cm	2.25 million Kg

ppm	lb/acre	Kg/hectare
0.5	1	1.12
1	2	2.24
0.89	1.78	1

A number of variables must be considered when interpreting soil test results in addition to the values obtained. These variables include the composition of the soil, drainage, climate, previous fertilizer programs, and the type of plant to be grown. Samples must also be truly representative of the area being studied and must be carefully selected.

SMART 3 Electronic Soil Laboratory (Selected Option)
User Manual

None

None

Specifications
Cable Length	1 m
Range	0 - 25% volume
Calibration	Oxygen
Detection Method	Electrochemical sensor
Response Time	Within 6 seconds
Sampling Method	Hand aspirated
Batteries	9 Volt transistor type
Operating Hours	Approx. 30
Operating Temperature	-12 to +45 °C
Weight	11 lb
