Joint Type

Outstanding Features

Multi-coated optics increase light transmission, resulting in brighter, sharper images with high levels of contrast.

The sleek, rubber-coated aluminum body protects from rough handling.

Ergonomic thumb grooves and finger edges for non-slip comfort and ease of use.

Water resistant.

Ref	7x35 Joint	8x21 Straight	8x40 Joint	10x25 Straight	10x50 Joint	16x32 Straight	20x50 Joint	10-30x50 Joint
Magnification	7x	8x		10x		16x	120x	10-30x
Objective lens diameter	35 mm	21 mm	40 mm	25 mm	50 mm	32 mm	50 mm
Angular field of view	9.2 °	7.4 °	8.2 °	5.7 °	6.8 °	3.5 °	3.2 °	4.3 ° @ 10x / 2.2 ° @ 30x
linear field of view (@ 1000 yds) / @ 1000 m)	483 pies (161 m)	378 pies (129 m)	429 pies (143 m)	300 pies (100 m)	354 pies (118 m)	185 pies (62 m)	168 pies (56 m)	225 pies (75 m) @ 10x / 115 pies (38 m) @ 30x
Exit Pupil	5 mm	2,6 mm	5 mm	2,5 mm	5 mm	2 mm	2,5 mm	5 mm (.19 ") @ 10x / 1.7 mm (.06") @ 30x
Ocular Distance	13 mm	11 mm	12 mm	11 mm	12 mm	10 mm	7 mm	20 mm @ 10x / 15 mm @ 30x
enfoque cercano	4 m	3 m	6 m	5 m	7 m	8 m	13 m	8 m @ 10x / 14 m @ 30x
Interpupillary Distance(Máx.)	72 mm
Interpupillary Distance (Min.)	56 mm	58 mm	56 mm	58 mm	56 mm	58 mm	56 mm
Diopter Adjustment Range	-4 a +8	± 2	TBD	± 2	-4 a +8	± 2	-4 a +8	-4 a +8
twilight Factor	15,65	12,96	17,89	15,81	22,36	22,63	31,62	22.36 @ 10x / 38.73 @ 30x
relative brightness	25	6,76	25	6,25	25	4	6,25	25 @ 10x / 2.77 @ 30x
Lens Coating	Multi Capa
prism glass	Bk7
Prism Coatings	N / A
Weight	624 g		680 g	312 g	765 g	369 g	794 g
Environmental Protection	Waterproof
Adaptable Tripod	Yes	No	Yes	No	Yes	No	Yes
Carrying Case	soft cloth
Dimensions	165 mm x 69 mm x 124 mm	69 mm x 51 mm x 91 mm	173 mm x 74 mm x 137 mm	76mm x 51mm x 11 4mm	185 mm x 81 mm x 160 mm	91 mm x 56 mm x 142 mm	185 mm x 81 mm x 160 mm
