Hydro-BIOS

Combined Plate Chamber (Utermöhl-Chamber) Hydro-Bios

$ 1,200.00 USD

⚠️ Do NOT use alcohol for cleaning acrylic parts.

The Combined Plate Chamber is a standard manufacture fitting virtually any type of inverted microscope.

As described in UNESCO's Phytoplankton Manual (published 1978) the Combined Plate Chamber allows you to look at sedimented plankton samples from a very short distance. How? Put the sample into a cylinder on top of the rectangular plexiglass plate with a thin base plate, let the fixed plankton concentrate and after sedimentation simply push the cylinder with excess liquid aside. The handling support underneath the plate will collect the extra water from the cylinder. You can now take the plate and examine the sample under an inverted microscope. Three calibrated cylinder sizes are provided with each set allowing to analyze different sample volumes.

The basic kit includes a set of cylinders 10 / 50 / 100 ml. Complete with cover plates, also base plates and handling support. The complete kit includes in addition a cylinder of 25 ml, and additional cover and base plates. Items can be purchased separately too.

The Base Plate Set, includes the Base Plate, the Threaded Ring and the Ring Detacher.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• - Base plate
  - Handling support base
  - Settling chamber, 10 ml capacity, height 15 mm
  - Settling chamber, 25 ml capacity, height 41 mm
  - Settling chamber, 50 ml capacity, height 92 mm
  - Settling chamber, 100 ml capacity, height 185 mm
  - Threaded ring and ring detacher
  - Round cover glass, Ø 33 mm, thickness 2,0 mm
  - Square cover glass, 42 x 42 mm, thickness 1,8 mm
  - Bottom plates, Ø 27,5 mm, thickness 0,2 mm
• Basic Chamber Kit:
  - Base Plate Set (1)
  - Settling Chamber 10 ml
  - Settling Chamber 50 ml
  - Settling Chamber 25 or 100 ml
  - Handling Support Base
  - Round Cover Glass x 3 u.
  - Square Cover Glass x 1 u.
  - Bottom Plates x 50 u.

  Complete Chamber Kit includes also:
  - All 4 Settling Chambers 10, 25, 50 and 100 ml.
  - Additional Square Cover Glass x 50 u.
  - Additional Round Cover Glass x 50 u.
  - Additional Bottom Plates x 250 u.
• The Basic and Complete kits doesn't need additional items. The Base Plate Set alone needs the other parts to work.
• Choose the Complete Chamber kit instead the Basic Chamber Kit.
• • User’s Manual (English)

Cámara de Sedimentación Combinada (Cámara Utermöhl)

Camara de Sedimentacion Combinada (Camara Utermohl)

View full product details »

Tubular Plankton Chambers Hydro-Bios

$ 351.75 USD

Tubular Plankton Chambers are used for microscopic analysis of plankton samples. The sedimentation process is carried out inside the original inspection cylinder to avoid any falsification of the samples during handling. The chamber consists of a plexiglass tube with an unscrewable metal base ring holding a thin base plate of just 0.2 mm. Analysis of the sample is made on inverted microscopes. Our scope of delivery includes one chamber, one glass cover plate and a set of 50 glass base plates.

• Specifications
• In the Box
• Required Items
• Optional Items

• - Material: Plexiglass, glass, chrome-plated brass
  - Diameter of base ring 43 mm
  - Diameter of base ring alignment 42 mm
  - Inner diameter of sedimentation tube 26 mm
  - Height of chamber
     approx. 10 mm for the 5 ml version
     approx. 19 mm for the 10 ml version
     approx. 46 mm for the 25 ml version
• - Chamber (1)
  - Cover Glass (1)
  - Bottom Plate (50)
• None
• - Round Cover Glass x 50 u.
  - Bottom Plate x 250 u.

Cámaras Tubulares de Placton

Tubular Plankton Chamber, Cámaras Tubulares de Placton, Cámara Tubular de Placton, Tubular Plankton Câmaras, Tubular Plankton Chambers

View full product details »

Folsom’s Plankton Sample Divider Hydro-Bios

$ 1,985.00 USD

Folsom’s Plankton Sample Divider provides a fast and easy method to divide large plankton samples...

View full product details »

Hydro-Bios Mechanical Flowmeter

$ 700.00 USD

Mechanical counter to quantify water filtered by plankton nets. The main application of the Mechanical...

View full product details »

Hydrobios Integrated Water Collector 100m

Request Quote

View full product details »

Hydro-BIOS Bottom Samplers acc. to Van Veen

$ 2,015.00 USD

The Bottom Sampler acc. to Van Veen is a qualitative sampler to achieve low-disturbed sediment samples in soft or medium hard grounds from any desired depth. It consists of two clamshell jaws connected by a hinge. During descent both levers are locked wide apart and the jaws are open. Upon touching the water bed the locking mechanism is released and when the rope is pulled taut to raise the sampler the jaws close. During retrieval the jaws are holding the sample and prevent sample wash-out. Additional flaps on top of the heavy version 437 333 allow to inspect the sample before retrieving.

• Specifications
• In the Box
• Required Items
• Optional Items

• Ref.	Overall Size	Material	Grasping Area	Weight
  437-330	20x30x60 cm	Stainless Steel	250 cm²	5.5 kg
  437-332	35x42x90 cm	Stainless Steel	1000 cm²	25 kg
  437-333	36x45x90 cm	Stainless Steel	1250 cm²	35 up to 65 kg

• - Grab (1)
  - Messenger (1)
  - Line (1)
• - None
• - Messenger

Dragas Ekman

Dredge, Dredges, Draga

View full product details »

Hydro-BIOS Bottom Samplers acc. to Ekman-Birge

$ 2,205.00 USD

The Bottom Sampler acc. to Ekman-Birge is a quantitative sampler with precise sampling area to achieve nearly undisturbed samples in soft grounds. It consists of a sturdy-walled metal cabinet equipped with two spring-loaded jaws which are released by a messenger. Two light plates cover the top opening of the sampler to prevent the sample from being washed out during ascent.

• Specifications
• In the Box
• Required Items
• Optional Items

• Ref.	Box Size (cm)	Material	Optional	Grasping Area	Weight
  437-200	15x15x20	Powder-coated Brass	None	225 cm²	3.5 kg
  437-201	15x15x20	Powder-coated Brass	w/ Perforated Stainless Steel Plate	225 cm²	3.5 kg
  437-210	15x15x20	Powder-coated Brass	Lead-weighted	225 cm²	7.5 kg
  437-212	15x15x20	Stainless Steel	None	225 cm²	3.5 kg
  437-213	15x15x20	Stainless Steel	Lead-weighted	225 cm²	7.5 kg
  437-214	20x20x35	Stainless Steel	None	400 cm²	7.0 kg
  437-215	20x20x35	Stainless Steel	Lead-weighted	400 cm²	11.0 kg

• - Grab (1)
  - Messenger (1)
  - Line (1)
• - None
• - Messenger

Dragas Ekman

Dredge, Dredges, Draga

View full product details »

Plunger Sampling Pipettes Hensen

$ 333.95 USD

Easy retrieval of precise small plankton sub-samples The Plunger Sampling Pipettes acc. to Hensen are...

View full product details »

ICES Incubator Hydro-Bios

$ 5,035.00 USD

ICES standard for phytoplankton primary production measurements.

One of the most important marine processes is the formation of organic material resulting from the interaction of carbon dioxide, water and sunlight, a process known as photosynthesis. The ability to measure this process is of great importance when assessing marine pelagic systems. In practice the best way to measure photosynthesis is to look at the absorption of carbon dioxide. The high sensitivity of carbon dioxide absorption measurements allows to use this method under all circumstances. Neither low or very high algal concentrations nor low light conditions and low temperatures are restrictions for this method.

Based on the 14C method, using the absorption of the radio-active 14C isotope of carbon (Steemann-Nielsen, 1952), the ICES Incubator is the ICES standard for phytoplankton primary production measurements.The incubator shown here has been mainly developed for monitoring purposes. It should be used preferably for water samples taken from a mixed water layer with a fixed temperature. Measurements of the amount of phytoplankton (based on chlorophyll-a concentration measurements) should be carried out for interpretation purposes.

The ICES Incubator consists of an illuminated transparent plexiglass tank incorporating a turning wheel on which 12 experimental bottles can be clamped. The tank is filled with water which is set in motion by an adjustable circulating pump. Thus the turning wheel is set in rotation at speeds up to 10 rpm with the experimental bottles acting as paddles. Tank connections for a second water circulation allow for temperature adjustments of the water by using external tempering equipment.

The 12 experimental bottles of 50 ml capacity each have different optical coatings, so that each bottle has individual transmission rates and thus generating a number of 12 different irradiance (or light intensity) levels. The illumination unit is equipped with 10 fluorescent tubes with a wave spectrum according to ICES specifications, each can be switched individually. For higher irradiance levels a second illumination unit can be mounted onto the ground plate of the ICES Incubator.

• Specifications
• In the Box
• Required Items
• Optional Items

• ICES Incubator:
  - 1 Ground plate with fixing screws for plexiglass tank and illumination unit, Dimensions: 510 x 325 x 20 mm
  - 1 Centrifugal pump (power supply 220 - 240 V AC, 50 / 60 Hz required), Hauling capacity: 10 l/min. 2 PVC tubings, 415 mm long
  - 1 Illumination Unit with 10 individually switchable fluorescent tubes (power supply 220 - 240 V AC, 50 / 60 Hz required) Dimensions: 350 x 335 x 150 mm
  - 1 Plexiglass tank with diaphragm valve and hose nozzles, Dimensions: 350 x 400 x 100 mm
  - 1 Turning wheel for 12 experimental bottles Dimensions: 180 mm dia.

  Experimental Bottles:
  50 ml capacity with optical coating, transmission rates: 0 - 100 %
• ICES Incubator:
  - 1 Ground plate
  - 1 Centrifugal pump
  - 1 Illumination Unit
  - 1 Plexiglass tank
  - 1 Turning wheel
• None
• - Spare Fluorescent Tubes
  - Experimental Bottles
  - Illumination Unit

Incubador ICES, Incubadora ICES

View full product details »
