HOBO Micro Station Data Loggers

Multichannel Data Logging Solution for Microclimates

Robust and compact, the redesigned HOBO USB Micro Station is a weather-resistant data logger for multichannel microclimate monitoring. This battery-powered station supports up to five plug-and-play smart sensors and features a hinged door for quick and easy sensor installation. The Micro Station comes with a built-in USB port for fast and efficient data readout to a computer and an integrated mounting tab for easy installation.

Features

Compact size for easy deployment.

IP66 weatherproof housing for harsh environments.

Direct USB download—no adapter cable required.

Includes five smart sensor inputs.

Hinged door and integrated mounting tabs.

Operates up to one year with four standard AA batteries.

Compatible with HOBOware and HOBOware Pro software for logger setup, graphing, and analysis.

What environments does this station operate in?

Indoor and outdoor environments.

What measurements does this station support?

4-20 mA, Amp Hour (Ah), barometric pressure, DC voltage, kilowatt hours (kWh), leaf wetness, light intensity, power factor (PF), pulse input, rain, relative humidity, soil moisture, temperature, reactive volt-amperes, reactive volt-amp hours, volt-amperes (VA), water flow, watt-hours (Wh), watts (W), and wind.

Features	Logger
Operating Range	-20 ° to 50 °C (-4 ° to 122 °F) with alkaline batteries -40 to 70 °C (-40 to 158 °F) with lithium batteries
Smart Sensor Connectors	5
Smart Sensor Data Channels	Up to 15 (some smart sensors use more than one data channel; refer to the sensor manual for details)
Smart Sensor Network Cable Length	100 m (328 ft) max
Logging Interval	1 second to 18 hours
Start Modes	Immediate, interval, push button, or delayed start
Memory	512 KB non-volatile flash data storage
Accuracy	0 to 2 seconds for the first data point and ±5 seconds per week at 25 °C (77 °F)
Battery	Four 1.5 V AA alkaline batteries for -20 ° to 50 °C (-4 ° to 122 °F). Four 1.5 V AA lithium batteries for -40 to 70 °C (-40 to 158 °F)
Enclosure Access	Hinged door secured with a latch and eyelet for user-supplied padlock
Dimensions	17.04 x 11.94 x 4.47 cm
Weight	414 g
Communication Type	USB 2.0 Interface
Environmental Rating	IP50
	CE marking identifies this product as complying with all relevant directives in the European Union (EU)
