$ 1,770.99 USD
It is a portable multiparametric meter with waterproof logging capability that monitors up to 12 water quality parameters, 6 measured and 6 calculated. The multisensor probe with a microprocessor allows measurement of key parameters such as pH, ORP, conductivity, dissolved oxygen, and temperature. The probe digitally transmits readings to the meter, where data points can be displayed and recorded. The use of digital communication enables noise-free data transfer up to a length of 100 meters. The complete system is easy to set up and user-friendly.
The meter features a backlit dot matrix display with on-screen graphics and the ability to automatically adjust digit sizes based on the number of selected parameters. Each measured parameter is fully configurable.
Designed to withstand demanding environments, it is the ideal solution for field measurements in lakes, rivers, and oceans. The meter complies with IP67 standards, and the multisensor probe complies with IP68 standards.
Instrument Specifications | ||
---|---|---|
pH / mV |
Range |
0.00 to 14.00 pH / ±600.0 mV |
Resolution |
0.01 pH / 0.1 mV |
|
Accuracy |
±0. 02 pH / ±0. 5 mV |
|
Calibration |
Automatic one, two, or three points with automatic recognition of five standard solutions (pH 4.01, 6.86, 7.01, 9.18, 10.01) or a custom value |
|
ORP |
Range |
±2000.0 mV |
Resolution |
0.1 mV |
|
Accuracy |
±1.0 mV |
|
Calibration |
Automatic single point custom (relative mV) |
|
EC (Electrical Conductivity) |
Range |
0 to 9999 µS/cm; 0.000 to 200.0 mS/cm (absolute EC up to 400.0 mS/cm) |
Resolution |
Manual: 1 µS/cm; 0.001 mS/cm; 0.01 mS/cm; 0.1 mS/cm; 1 mS/cm; Auto-range: 1 µS/cm from 0 to 9999 µS/cm; 0.01 mS/cm from 10.00 to 99.99 mS/cm; 0.1 mS/cm from 100.0 to 400.0 mS/cm; Auto-range (fixed mS/cm): 0.001 mS/cm from 0.000 to 9.999 mS/cm; 0.01 mS/cm from 10.00 to 99.99 mS/cm; 0.1 mS/cm from 100.0 to 400.0 mS/cm |
|
Accuracy |
±1% of reading or ±1 µS/cm, whichever is greater |
|
Calibration |
Automatic single point with six standard solutions (84 µS/cm, 1413 µS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 111.8 mS/cm) or a custom point |
|
TDS (Total Dissolved Solids) |
Range |
0 to 9999 ppm (mg/L); 0.000 to 400.0 ppt (g/L) (maximum value depends on TDS factor) |
Resolution |
Manual: 1 ppm (mg/L); 0.001 ppt (g/L); 0.01 ppt (g/L); 0.1 ppt (g/L); 1 ppt (g/L); 0.01 ppt (g/L) from 10.00 to 99.99 ppt (g/L); 0.1 ppt (g/L) from 100.0 to 400.0 ppt (g/L);
0.01 ppt (g/L) from 10.00 to 99.99ppt (g/L); 0.1 ppt (g/L) from 100.0 to 400.0 ppt (g/L) |
|
Accuracy |
±1% of reading or ±1 ppm (mg/L), whichever is greater | |
Calibration |
Based on the electrical conductivity calibration | |
Resistivity |
Range |
0 to 999999 Ω•cm; 0 to 1000.0 kΩ•cm; 0 to 1.0000 MΩ•cm |
Resolution |
Depends on the resistance reading |
|
Calibration |
Based on electrical conductivity calibration |
|
Salinity |
Range |
0.00 to 70.00 PSU |
Resolution |
0.01 PSU |
|
Accuracy |
±2% of reading or ±0.01 PSU, whichever is greater |
|
Calibration |
based on electrical conductivity calibration |
|
Seawater Σ |
Range |
0.0 to 50.0 Σt, Σ₀, Σ₁₅ |
Resolution |
0.1 Σt, Σ₀, Σ₁₅ |
|
Accuracy |
±1 Σt, Σ₀, Σ₁₅ |
|
Calibration |
based on electrical conductivity calibration |
|
Dissolved Oxygen |
Range |
0.0 to 500.0%; 0.00 to 50.00 ppm (mg/L) |
Resolution |
0.1%; 0.01 ppm (mg/L) |
|
Accuracy |
0.0 to 300.0%: ±1.5% of reading or ±1.0% whichever is greater; 300.0 to 500.0%: ±3% of reading; 0.00 to 30.00 ppm (mg/L): ±1.5% of reading or ±0.10 ppm (mg/L), whichever is greater; 30.00 ppm (mg/L) to 50.00 ppm (mg/L): ±3% of reading |
|
Calibration |
Automatic at one or two points at 0% and 100% or a custom point |
|
Atmospheric Pressure |
Range |
450 to 850 mm Hg; 17.72 to 33.46 in Hg; 600.0 to 1133.2 mbar; 8.702 to 16.436 psi; 0.5921 to 1.1184 atm; 60.00 to 113.32 kPa |
Resolution |
0.1 mm Hg; 0.01 in Hg; 0.1 mbar; 0.001 psi; 0.0001 atm; 0.01 kPa |
|
Accuracy |
±3 mm Hg at ±15°C temperature during calibration |
|
Calibration |
Automatic at a custom point |
|
Temperature |
Range |
-5.00 to 55.00°C; 23.00 to 131.00°F; 268.15 to K 328.15 |
Resolution |
0.01°C; 0.01°F; 0.01 K |
|
Accuracy |
±0.15°C; ±0.27°F; ±0.15K |
|
Calibration |
Automatic at a custom point |
|
Additional Specifications |
Temperature Compensation |
Automatic from -5 to 55°C (23 to 131°F) |
Memory Logging |
45,000 logs (continuous or on-demand logging of all parameters) |
|
Logging Interval |
one second to three hours |
|
PC Connectivity |
USB for PC with Hanna HI9298194 software |
|
Environment |
0 to 50°C (32 to 122°F); HR 100% IP67 |
|
Battery Type / Life |
1.5V AA batteries (4) / approximately 360 hours of continuous use without backlight (50 hours with backlight) |
|
Dimensions / Weight |
185 x 93 x 35.2 mm (7.3 x 3.6 x 1.4") / 400 g (14.2 oz.) |
Probe Specifications | ||
---|---|---|
Probe |
HI7698194 |
|
Sensors |
3 (pH, DO, EC) |
|
Environmental Samples |
Freshwater, brackish, seawater |
|
Protection |
IP68 |
|
Operating Temperature |
-5 to 55°C |
|
Storage Temperature |
-20 to 70°C |
|
Maximum Depth |
20 m (66') |
|
Dimensions (without cable) |
342 mm (13.5 inches); diameter 46 mm (1.8 inches) |
|
Weight (without batteries and sensors) |
570 g (20.1 oz.) |
|
Cable Specification |
Multi-conductor shielded cable with internal junction rated for use up to 68 kg (150 lb). Intermittent use |
|
Materials for Moisture |
Body |
ABS |
Threaded Fittings |
Nylon |
|
Guard |
ABS / 316 SS |
|
Temperature Probe |
316 SS |
|
O-rings |
EPDM |
Sensor Specifications | |||||
---|---|---|---|---|---|
Sensor |
HI7698194-0 |
HI7698194-1 |
HI7698194-3 |
HI7698194-2 |
|
Description |
pH Sensor |
pH/ORP Sensor |
EC Sensor |
OD Sensor |
|
Measurement Type |
pH, pH-mV |
pH, pH-mV, ORP |
EC, TDS, salinity |
OD (% saturation and |
|
Measurement Range |
0.00 to 13.00 pH; ±600.0 pH-mV |
pH from 0.00 to 13.00; ±600.0 pH mV; ±2000.0 mV (ORP) |
0.0 to 200.0 mS/cm; (absolute) |
0.0 to 500.0%; |
|
Temperature Range |
-5 to 55 °C |
-5 to 55 °C |
-5 to 55 °C |
-5 to 55 °C |
|
Color Code |
Red |
Red |
Blue |
White |
|
Materials |
Tip (pH) |
Glass (pH) |
Glass (pH); Pt (ORP) |
Stainless Steel AISI 316 |
Cat / an: Ag/Zn |
Junction |
Ceramic |
Ceramic |
N/A |
High-Density Polyethylene Membrane |
|
Body |
PEI |
PEI |
ABS/epoxy |
White ABS tip |
|
Electrolyte |
Gel |
Gel |
N/A |
N/A |
|
Reference |
Double |
Double |
N/A |
N/A |
|
Maintenance Solution |
HI70300 (Storage Solution) |
HI70300 (Storage Solution) |
None |
HI7042S (Electrolyte) |
|
Dimensions |
118 x 15 mm |
118 x 15 mm |
111 x 17 mm |
99 x 17 mm |
|
Maximum Depth |
20 m (65') |
20 m (65') |
20 m (65') |
20 m (65') |
EO 20230831
$ 108.75 USD
YSI pH calibration buffer solutions are essential to ensure accuracy and repeatability in your pH measurements for scientific, environmental, and laboratory applications. Formulated under strict quality controls, these solutions allow calibration of the entire line of YSI sensors and meters, ensuring confidence in your results and meeting international standards.
Specification | YSI 3821 pH 4.00 |
YSI 3822 pH 7.00 |
YSI 3823 pH 10.00 |
---|---|---|---|
Identifier Color | Red | Yellow | Blue |
Main Ingredients | Potassium Acid Phthalate, Deionized Water |
Potassium Phosphate Monobasic, Sodium Hydroxide, Deionized Water |
Disodium EDTA, Potassium Carbonate, Potassium Borate, Potassium Hydroxide, Deionized Water |
Packaging | Plastic bottles (pint) or glass bottles (quart) | ||
Shelf Life (unopened) | 2 years | 2 years | 2 years |
Shelf Life (opened) | 6 months | 6 months | 6 months |
Main Use | Low acidity calibration | Neutral calibration | Basic/high alkalinity calibration |
Request Quote
The Oakton pH 6+ portable meter is a compact instrument designed to deliver fast and accurate results. This versatile device can display pH, mV, and temperature readings at the push of a button. Its Automatic Temperature Compensation (ATC) system ensures accurate measurements in a range of 0 to 100 °C. The meter comes equipped with a rubber boot that not only protects it but also serves as a convenient stand. With the ability to calibrate up to five points and compatibility with NIST and USA buffer recognition, this meter is a reliable tool for both field and laboratory applications. The different available packages allow users to choose between the meter only, the meter with a pH probe, or a complete kit that includes buffer solutions, sample bottles, a rinse bottle, and a carrying case.
Meter, portable, pH, mV, temperature, ATC, automatic, calibration, buffer, NIST, USA, LCD, battery, accuracy, Oakton, kit, probe, solutions, case, warranty, compact.
Meter Type | Portable |
Display Type | LCD |
Minimum pH (pH) | 0 |
Maximum pH (pH) | 14 |
pH Resolution | 0.01 or 0.1 |
pH Accuracy | ±0.01 pH |
Buffer Recognition | NIST and USA |
Calibration | Up to 5 points |
Minimum mV (mV) | -1999 |
Maximum mV (mV) | 1999 |
mV Resolution | 1 mV |
mV Accuracy | ±0.2 mV or 0.05%, whichever is greater |
Minimum Temperature (°C) | -10 |
Maximum Temperature (°C) | 110 |
Temperature Compensation | Automatic |
Battery | 4 AAA (included) |
Battery Life (hr) | 700 |
Width (cm) | 8.5725 |
Height (cm) | 4.28625 |
Width (in) | 3 3/8 |
Height (in) | 1 11/16 |
Warranty | 3 years |
(The following items are included in specific packages:)
Request Quote
The HI1332D pH Electrode with Special DIN Connection is designed to provide accurate and stable measurements in a wide range of chemical, field, and quality control applications. Its double junction reference, durable PEI body, and spherical tip design make it ideal for demanding environments. This electrode is compatible with pH meters that incorporate the CAL CHECK system, offering a robust solution for users who require reliable data with low maintenance.
Specification | Details |
---|---|
Reference | Double, Ag/AgCl |
Junction / Flow | Single ceramic / 15-20 μL/h |
Electrolyte | KCl 3.5M |
Maximum Pressure | 0.1 bar |
pH Range | 0 to 13 |
Operating Temperature | 20 to 40 °C (68 to 104 °F) |
Tip / Shape | Spherical (Ø 7.5 mm) |
Temperature Sensor | No |
Amplifier | No |
Body Material | PEI |
Cable | Coaxial; 1 m (3.3') |
Connection | Special DIN with screw-type metal banana connector |
Compatibility | pH meters with CAL CHECK system (not compatible with models using a threaded cap) |
Request Quote
The Edge® pH/ORP dedicated meter combines the advanced functionality of a laboratory instrument with the portability of a tablet-style design. Thanks to its intelligent diagnostic system and compatibility with digital electrodes, it ensures accurate and reliable results at all times. Designed for scientists, technicians, and demanding professionals, this meter enables reliable measurements in the field or laboratory with an intuitive interface and multiple connectivity options.
Parameter | Value |
---|---|
pH Range | -2.000 to 16.000 (Standard Mode), -2.00 to 16.00 (Basic Mode) |
pH Resolution | 0.001 / 0.01 pH |
pH Accuracy | ±0.002 / ±0.01 pH |
pH Calibration | Up to 5 points (standard mode), 3 points (basic mode) |
Temperature Compensation | ATC: -5.0 to 100.0 °C (23.0 to 212.0 °F) |
mV Range | ±1000.0 mV; ±2000.0 mV |
mV Resolution / Accuracy | 0.1 mV / ±1000.0 mV; ±2000.0 mV |
mV Calibration | 1 point |
Temperature Range | -20.0 to 120.0 ºC / -4.0 to 248.0 ºF |
Temperature Resolution / Accuracy | 0.1 °C / ±0.5 °C |
Electrode Diagnostics | Glass and reference junction (HI11311 & HI12301) |
GLP | Yes |
Logging Capacity | Up to 1000 readings (manual, by stability, or at intervals) |
Connectivity | 1 micro-USB port, 1 standard USB port |
Environmental Conditions | 0 to 50 °C, max RH 95% non-condensing |
Battery | Rechargeable, up to 8 hours of continuous use |
Power Supply | 5 VDC adapter (included) |
Request Quote
The LaMotte Tracer PockeTester for pH and Temperature allows direct pH readings from 0.01 to 14.00 pH. The Tracer offers simultaneous displays of pH and temperature, with memory storage for 15 readings. The pH range is from 0.00 to 14.00 pH / 0.01 pH. The temperature range is from 5°C to 90°C.
Test Factors | Range | Resolution | Accuracy |
---|---|---|---|
pH | 0.00 to 14.00 pH | 0.01 pH | ± 0.01 pH |
Temperature | 0 to 65°C | 0.1°F / °C | ± 1.8°C |
(S 18/6/2021)
Request Quote
The PockeTester™ is designed for pool professionals, allowing the measurement of five parameters: Conductivity, TDS, Salinity, pH, and Temperature with a single electrode. It has memory that stores up to 25 labeled readings and includes automatic shut-off and low battery alert functions.
Test Factor | Range | Resolution | Accuracy |
---|---|---|---|
TDS | 0 to 99.9 ppm (mg/L), 100 to 999 ppm (mg/L), 1.00 to 9.99 ppt | 0.1 ppm (mg/L) | ±2% |
Salinity | 0 to 99.9 ppm (mg/L), 100 to 999 ppm (mg/L), 1.00 to 9.99 ppt | 0.1 ppm (mg/L) | ±2% |
pH | 0.00 to 14.00 pH | 0.01 pH | ±0.01 pH |
Temperature | 32° to 149°F (0 to 65°C) | 0.1°F/°C | ±1.8°F/°C |
Request Quote
The soil pH hygrometer measures pH and moisture values of different soils. The soil pH tester can test pH values from 3 to 8 pH and moisture from 1 to 8 to meet your daily soil maintenance needs.
pH Accuracy: ± 0.2, Resolution: ± 0.2 pH, quickly and accurately measures pH and moisture levels.
The soil pH meter is certified according to strict quality and safety standards for quickly and accurately measuring pH and moisture levels. The sensitive probe can detect changes in the terrain and transfer the details to the reader to display the exact value.
It comes with a safe and waterproof self-powered metal electrode, needle-type. It ensures durability for a long and trouble-free life.
Soil pH meter highly suitable for quick reference of pH and moisture in vines, orchards, field crops, nurseries, lawn maintenance, and gardens.
Features |
|
---|---|
pH Range | 3 ~ 8 pH |
Moisture | 1 ~ 8 (10% ~ 80%) |
pH Accuracy | ± 0.3 |
Resolution | ± 0.2 pH |
Operational Temperature | 5 ~ 50C (41 ~ 122 F) |
Size | 165 mm x 50 mm (diameter) |
Weight | 145 g |
EO 20230818
$ 688.25 USD
Rugged and reliable, the YSI Pro10 provides everything you need in a handheld instrument for the measurement of either pH or ORP along with temperature.
User-replaceable sensors and cables along with convenient calibration routine feature makes it extremely user friendly. Mil-spec (military spec) connectors, IP67 waterproof and rubber over molded case, and 1-meter drop tests ensure the instrument remains in your hands to provide years of sampling even in the harshest field conditions. The feature set results in a low total cost of ownership over the life of the product and proves that it is smarter, tougher, and more versatile.
Note: cables and sensors are sold separately
Características |
|
---|---|
Certifications: | RoHS, 1-meter drop test, Assembled in USA, IP-67, CE, WEEE |
Connector: | MS (military spec) waterproof with bayonet lock |
Digital / Digital Sensors: | Analog |
Equipment used with: | ProSeries 10-x, 1007-x and 1008-x |
Graphic Display: | Graphic display with detailed Help, backlit display AND keypad |
Languages: | English, French and Portuguese, Spanish |
Logging Capabilities: | Single |
Measurement Range: | pH: -2 to 14 units Temperature: -5 to 55°C ORP: -1500to +1500 mV Temperature: -10 to +120°C (14 to 248°F) |
Memory: | 50 data sets |
Multiparameter: | Yes |
Operating pH Range: | 0 to 14 units |
Parameters Measured: | Temperature, pH, ORP |
Power: | 2 alkaline C-cells provide 425 continuous hours at ambient temperature without backlight |
Sampling: | Yes |
Unit of Measure: | ORP- mV, Temperature- °C, pH-unit |
User Calibratable | Yes |
User Replaceable | Yes |
Waterproof: | IP-67 (even with the battery cover off), floats |
EO20231804
