Petzl

Comfortable harness for the gym, single pitch, or multi-pitch routes

Comfortable and Versatile Harness, Ideal for Sport Climbing in Climbing Gyms, Walls, and Multi-Pitch Routes

Whether you’re at the gym or the crag, the SAMA is a comfortable harness for your sport climbing sessions! The elasticized leg loops provide a dynamic fit and the waistbelt is flexible and slimmer in front to give great freedom of movement. Four gear loops provide enough space to rack all the gear you need, including for multi-pitch climbing.

Features

• Comfortable harness offering great freedom of movement:
  • Waistbelt and leg loops are tapered and have smooth-seamed edges for comfortable support
  • Great freedom of movement, with elasticized leg loops and flexible connection straps, helping keep the harness in place
  • FRAME Technology construction allows optimal weight distribution
  • Breathable, moisture-wicking interior fabric
• Capacity for carrying gear:
  • Two front gear loops are rigid to easily clip and unclip quickdraws
  • Two rear gear loops are flexible, angled to bring gear to the front, and comfortable when carrying a backpack
  • Rear accessory loop for chalk bag, shoes, quick link, tag line, or other gear
  • Compatible with CARITOOL EVO tool holders for racking ice screws
• Eco-design:
  • Waistbelt and leg loop exterior fabric is made from 100% recycled polyester
  • The DARK GRAY version features an irregular pattern, limiting fabric waste in production Every harness is unique!

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications

  • Material(s): Polyester, 100 % recycled polyester, EVA, polyurethane, high-modulus polyethylene, aluminum
  • Certification(s): CE EN 12277 type C, UIAA
  • Comes with a storage pouch made from 100 % recycled polyester fabric

  References

  References	C021CA00	C021CA01	C021CA02	C021CA03	C021CA04	C021CA05	C021CA06	C021CA07
  Color(s)	ATLANTIC BLUE				DARK GRAY
  Size	S	M	L	XL	S	M	L	XL
  Waist Belt	71-77 cm	77-84 cm	84-92 cm	92-100 cm	71-77 cm	77-84 cm	84-92 cm	92-100 cm
  Leg Loops	48-53 cm	52-57 cm	55-60 cm	57-62 cm	48-53 cm	52-57 cm	55-60 cm	57-62 cm
  Weight	310 g	330 g	355 g	375 g	310 g	330 g	355 g	375 g
  Inner Pack Count	1

• • SAMA harness
  • Instruction manual
  • Declaration of conformity
  • Storage bag made of 100% recycled polyester
• • Climbing rope
  • Carabiners
  • Belay device
• • Chalk bag
  • Climbing shoes
  • Quick link
  • Hauling line
  • CARITOOL EVO tool holders
• • Technical-notice-FOCUS-2
  • Tips for maintaining your equipment

Tree Care Seat Harness for Single-Rope Ascent Techniques

Harness SEQUOIA SRT: Designed for Arborists Utilizing Single Rope Techniques

SEQUOIA® SRT is a tree care seat harness for ascents on a single rope. It has a ventral attachment point that allows a ZIGZAG or ZIGZAG PLUS mechanical Prusik to be installed with CHICANE and KNEE ASCENT accessories. The extra-wide, semi-rigid waistbelt and leg loops provide comfort for the arborist. It is equipped with DOUBLEBACK PLUS self-locking buckles on the waistbelt and FAST LT PLUS buckles on the leg loops. The gated attachment points allow the user to easily connect a ZILLON or MICROFLIP lanyard, or to install several attachment bridges and accessories directly on the bridge. The harness also makes it easy to carry and organize work tools, with multiple equipment loops and slots for attaching CARITOOL tool holders.

Features

• Harness designed for using single-rope ascent techniques: ventral attachment point for installing a ZIGZAG or ZIGZAG PLUS mechanical Prusik with CHICANE and KNEE ASCENT accessories, and a rear buckle for installing a CROLL ventral rope clamp with SECUR shoulder straps.

Built for comfort:

• Semi-rigid, wide waistbelt and leg loops for excellent positioning; sculpted and lined with foam padding for comfort during suspension
• Two gated attachment points allow the user to easily connect a ZILLON or MICROFLIP lanyard, or to install several attachment bridges (fixed or adjustable) and accessories directly on the bridge (RING, SWIVEL)
• Attachment bridge provides lateral mobility
• Mobile side attachment points allow the user to follow the orientation of the lanyard during lateral movement
• Ventral attachment point has textile bridge to improve comfort when walking

Easy to adjust:

• Waistbelt equipped with self-locking DOUBLEBACK PLUS buckles for quick and easy adjustment
• Leg loops equipped with FAST LT PLUS buckles for quick and easy fastening and unfastening without loss of adjustment, even while wearing gloves; the buckle’s locking system limits the risk of accidental unfastening
• DOUBLEBACK buckles for adjusting the height of the attachment bridge and allowing the arborist to position him/herself comfortably; the buckles have a plastic cover to help keep them locked

Easy to carry and organize tools:

• Nine pre-shaped equipment loops with protective sheath
• Five slots for CARITOOL tool holder
• Two retainers for a carabiner to hold a chainsaw or handsaw
• Elastic band for attaching a first aid kit

Can be accessorized in order to adapt the harness to its use:

• Seat: improves comfort during prolonged suspension
• Shoulder straps: connect to the ventral attachment point and the two rear slots on the waistbelt to transfer the load from the waistbelt to the shoulders

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications

  Attachment points:	Attachment bridge, gated attachment points, ventral attachment point, side attachment points
  Certification(s):	CE EN 358, CE EN 813, EAC, GB 6095 / W
  Material(s):	Nylon, polyester, polyethylene, aluminum, steel

  References

  References	C069BA00	C069BA01	C069BA02
  Color(s)	Black/Yellow	Black/Yellow	Black/Yellow
  Size	0	1	2
  Waist Belt	65-80 cm	70-93 cm	83-120 cm
  Leg Loops	44-59 cm	47-62 cm	50-65 cm
  Weight	1580 g	1630 g	1700 g
  Inner Pack Count	1	1	1

• • Arnés SEQUOIA SRT
  • Manual de usuario
  • Guía de verificación del arnés
  • Especificaciones técnicas
• • Climbing rope
  • Climbing helmet
  • Belay device
  • Safety carabiners
  • Climbing shoes
• • Climbing gloves
  • Sunglasses or protective glasses
  • Appropriate climbing clothing
  • Chalk bag and chalk
  • First aid kit
  • Additional gear holder
• • Technical-notice-SEQUOIA-SRT-3
  • Tips for maintaining your equipment

Ergonomic, Ultra-powerful, and Rechargeable

Rechargeable headlamp with 1500 lumens and REACTIVE LIGHTING® technology that automatically adjusts the light intensity according to the ambient light, offering an ergonomic and lightweight design of 145 grams for maximum comfort during long-distance runs.

The new icon for trails and ultra-trails! The NAO RL rechargeable headlamp offers a power of 1500 lumens with only 145 grams. Comfortable, its strap adjusts easily and maintains excellent support during long and demanding runs. Thanks to REACTIVE LIGHTING® technology, the power of its lighting automatically adapts to the ambient brightness. Manipulations are reduced and autonomy is optimized. Its red lighting at the back also ensures you are well visible at night.

Features

• Ultra-powerful and lightweight: 1500 lumens for only 145 g.
• Lighting that automatically adapts to the ambient brightness:
• Wide and homogeneous light beam that allows comfortable visibility at hand or feet level.
• Mixed light beam (wide and focused) that allows visibility both near and far for movement.
• Three levels of white lighting: MAX BURN TIME (maximum autonomy), STANDARD (best power/autonomy balance), and MAX POWER (maximum power).
• More autonomy, visual comfort, and reduced manipulations with REACTIVE LIGHTING® mode: the lighting power and beam shape automatically adapt thanks to a brightness sensor that optimizes battery usage.
• Minimum guaranteed autonomy of 5 hours in REACTIVE LIGHTING® mode (STANDARD level) for long activities like trails and ultra-trails.
• Red lighting, fixed or flashing, at the back of the headlamp. An independent button allows quick activation or deactivation.
• Ergonomic:
• Power source moved to the back to distribute the weight of the headlamp across the head for balanced and comfortable wear.
• Thin and flexible front plate to perfectly fit all morphologies.
• Easy and quick adjustment at the back.
• Additional top strap for optimal support.
• 3200 mAh lithium-ion battery, rechargeable via a USB type C connector.
• Possibility of having a spare battery for long-distance trails or simply to replace the battery when it reaches the end of its life (R1 battery available as an accessory).
• Charging indicator with five-level indicator that accurately shows the battery level.
• Possibility to use the R1 battery as an auxiliary battery to recharge other devices (phone, watch...).
• LOCK function to prevent accidental activation during transport/storage or to lock the lighting configuration during activity.
• Reflective strap for night visibility.
• Storage pouch that allows transforming the headlamp into a lamp with STANDARD mode or storing it with an additional battery.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• • Power: 1500 lumens (ANSI FL 1 standard)
  • Weight: 145 g
  • Technology: REACTIVE LIGHTING® or STANDARD LIGHTING
  • Type of light beam: wide or mixed
  • Power supply: 3200 mAh lithium-ion battery (included)
  • Charging time: 3h30
  • Water resistance: IPX4 (resistant to water projections)
  • Certifications: CE

  Lighting Performance
  Lighting Technology	Lighting Color	Lighting Levels	Luminous Flux	Range	Autonomy	Reserve
  REACTIVE LIGHTING®	white	MAX BURN TIME	15 to 250 lm	70 m	10 to 64 h	10 lm for 2 h
  		STANDARD	30 to 550 lm	100 m	5 to 40 h
  		MAX POWER	50 to 1500 lm	200 m	2 to 24 h
  STANDARD LIGHTING		MAX BURN TIME	10 lm	10 m	80 h
  		STANDARD	250 lm	70 m	5 h
  		MAX POWER	900 lm	140 m	2 h
  STANDARD LIGHTING	rear red	fixed	2 lm	2.5 m	78 h	-
  		flashing	visible at 150 m for 400 h
  *Lighting performance according to ANSI/PLATO FL 1 protocol

• • NAO RL headlamp
• • None
• • Petzl CORE Battery
• • Technical Notice technical-notice-NAO-RL-1
  • Technical Information technical-information-ANSI
  • Technical Notice NAO ACCESSORIES COMPATIBILITY
  • Declaration of Conformity
  • Maintenance Tips for Your Equipment

Advanced Self-braking Descender with Anti-panic Function for Rescue Operations

Designed for rescues, the I’D® L features an ergonomic handle for comfortable descent control, integrated anti-panic function, and AUTO-LOCK system for secure positioning. Compatible with ropes from 12.5 to 13 mm.

The self-braking descender I'D L is primarily intended for technical rescues. It is equipped with an ergonomic handle that allows comfortable control of the descent. The integrated anti-panic function and error indicator cam limit the risk of accidents in case of misuse. The AUTO-LOCK system allows immobilization without having to manipulate the handle or perform a locking knot. Once locked, the rope can be retrieved without having to manipulate the handle. The closing trigger allows the rope to be installed while keeping the device connected to the harness. The I'D L is compatible with ropes from 12.5 to 13 mm and allows handling loads up to 280 kg.

Features

• Designed for technical rescues.

• It has a closing trigger on the movable side plate that allows the rope to be easily installed while keeping the device connected to the harness.
• Easy rope installation, thanks to the guide and indicative markings.
• Error indicator cam to limit the risk of accidents due to incorrect rope placement.
• Ergonomic handle that allows the rope to be released and comfortably control the descent. Two possible descent modes: on the side plate or in the V-shaped braking groove.
• Anti-panic function that automatically stops the descent if the user pulls too hard on the handle.
• Allows smooth movement on horizontal or inclined planes.
• AUTO-LOCK system that allows immobilization without having to manipulate the handle or perform a locking knot: as soon as the user releases the handle, the rope is automatically locked in the device. The automatic return of the handle limits the risk of unintentional snagging.
• Automatic handle transition to the storage position when the rope is removed from the device, reducing the risk of unintentional snagging when the descender is carried on the harness.

• Once locked, the rope can be retrieved without having to manipulate the handle, allowing a lifting system to be converted into a reversible one or easily perform short rope ascents.
• Cam that can be manipulated to easily retrieve the rope or belay a lead climber in climbing technique.
• Screw that allows the movable side plate to be locked to integrate the I'D L into rescue kits.
• Protection reinforcement, made of stainless steel in the rope friction zone, which increases wear resistance.
• Heavy load descent up to 280 kg.
• Rope compatibility: 12.5 to 13 mm in diameter.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	600 g
  Materials	Aluminum, steel, and polyamide
  Maximum Load for One Person	Up to 150 kg
  Maximum Load for Two People (Rescue)	Up to 280 kg
  Certifications	EN 341 type 2 class A, CE EN 12841 type C, ANSI Z359.4, NFPA 1983 General Use, and EAC - EN 341 type 2 class A used with a VECTOR 12.5 mm rope. - EN 12841 type C used with an EN 1891 A rope of 12.5 to 13 mm. - ANSI Z359.4 used with a rope of 12.5 to 13 mm. - NFPA 1983 General Use used with a rope of 12.5 to 13 mm.

• • Petzl Self-braking Descender with Anti-panic Function I’D L (1)
• • Climbing Equipment
• • Climbing Equipment
• • Technical notice
  • Declaration Of Conformity
  • Tips for maintaining your equipment

Versatile and Durable Lighting for Outdoor Activities

Ideal Headlamp for Exploring Nature in the Dark: Perfect for Hunting, Fishing, Nature Observation, and Animal Spotting

The Petzl ARIA 1 RGB headlamp is the ideal companion for your outdoor adventures. With a powerful white light and red, green, and blue lighting options, this lamp offers versatility for various situations, from night hikes to fishing activities. Its robust and waterproof design ensures optimal performance in extreme conditions. Additionally, its rechargeable battery ensures long-lasting use, allowing you to enjoy your activities without worries. Discover a new way to light your path with the ARIA 1 RGB from Petzl!

Features

• Wide, uniform beam for comfortable close-up or around-your-feet visibility
• Color lighting for different situations: red preserves night vision and provides stealth, green facilitates map reading and increases contrast, and blue helps identify blood trails and improves visibility in water without scaring fish
• Color lighting can be continuous or intermittent, depending on user needs
• Dust and water-resistant (up to 1 meter deep for 30 minutes)
• Compact and lightweight: only 105 g

Easy to use:

• A single button for quick and easy selection of brightness or light color
• Three levels of white lighting: MAX BURN TIME, STANDARD (best balance between power and duration), and MAX POWER
• Battery charge indicator shows battery level each time the lamp is turned on or off
• The plate allows easy tilting of the lamp up or down
• Detachable and washable headband
• Lock function to prevent the lamp from turning on during transport or storage

Versatile:

• HYBRID CONCEPT design: the ARIA 1 RGB includes three AAA/LR03 batteries and is also compatible with the CORE rechargeable battery (not included)
• The lamp detects the power source and optimizes lighting performance: with a CORE rechargeable battery, the lamp provides more brightness when turned on (450 lm in MAX POWER mode) and throughout the usage time
• Compatible with HELMET ADAPT and BIKE ADAPT 2 mounts, allowing you to attach the lamp to a helmet or bicycle

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

•

  References	E069BA00	E069BA01
  Color(s)	Black	Camo
  Internal package quantity	1	1
  Brightness:	350 lumens (ANSI/PLATO FL 1)
  Weight:	105 g
  Beam pattern:	Wide
  Power:	Three AAA/LR03 batteries (included) or CORE rechargeable battery (available as an accessory)
  Battery compatibility:	Alkaline, lithium, or Ni-MH rechargeable
  Certification(s):	CE, UKCA
  Water resistance:	IP67



  	Lighting Performance According to ANSI/PLATO FL 1 Protocol
  Lighting Color	Lighting Levels	Brightness	Distance	Usage Time	Reserve Lighting
  White	MAXIMUM TIME	7 lm	10 m	110 h	-
  	STANDARD	100 lm	45 m	12 h	20 h
  	MAXIMUM POWER	350 lm	70 m	2 h	-
  Red/Green/Blue	Continuous	4 lm	5 m	50 h	-
  	Strobe	Visible at 700 m for 300 h



  	Lighting Performance According to ANSI/PLATO FL 1 Protocol
  Lighting Color	Lighting Levels	Brightness	Distance	Usage Time	Reserve Lighting
  White	MAXIMUM TIME	7 lm	10 m	110 h	-
  	STANDARD	100 lm	45 m	7 h	2 h
  	MAXIMUM POWER	450 lm	75 m	2 h	-
  Red/Green/Blue	Continuous	4 lm	5 m	50 h	-
  	Strobe	Visible at 700 m for 300 h

• • Petzl ARIA 1 RGB headlamp
  • Three AAA/LR03 batteries
  • Adjustable and washable headband
  • Instruction manual
• • None
• • CORE rechargeable battery (not included)
  • HELMET ADAPT mount for attaching the lamp to a helmet
  • BIKE ADAPT 2 mount for attaching the lamp to a bicycle
• • Download the PDF: technical-information-ANSI
  • Download the PDF: technical-notice-ARIA-1
  • Accessory Compatibility - PRO HEADLAMPS
  • Declaration of Conformity
  • Tips for Maintaining Your Equipment

Versatile Lighting for Outdoor Activities

Experience the Freedom of Colors on Your Path with ARIA 2 RGB, Perfect for Hiking, Camping, and More

The Petzl ARIA 2 RGB headlamp offers multicolor lighting that adapts to different situations and needs in your outdoor activities. With white, red, green, and blue light modes, this headlamp is ideal for maintaining night vision, signaling, and map reading. Its ergonomic and rechargeable design ensures comfort and durability, making it an indispensable option for hikers, campers, and adventurers.

Features

• Powerful headlamp ideal for exploring nature at night (hunting, fishing, nature observation, and animal spotting):
  • Wide and mixed beam (wide and focused) for proximity and distance vision
  • Color lighting for different situations: red preserves night vision and provides stealth, green facilitates map reading and increases contrast, and blue helps identify blood trails and improves visibility in water without scaring fish
  • Color lighting can be continuous or strobe, depending on user needs
  • Dustproof and waterproof (up to 1 meter deep for 30 minutes)
  • Lightweight, compact, and bright: 450 lumens and only 106 g
• Easy to use:
  • Single button for quick and easy selection of brightness or light color
  • Three levels of white lighting: MAX BURN TIME, STANDARD (best balance of power/use time), and MAX POWER
  • Battery charge indicator shows battery level each time the lamp is turned on or off
  • Plate allows easy tilting of the lamp up or down
  • Detachable and washable headband
  • LOCK function prevents the lamp from turning on during transport or storage
• Versatile:
  • HYBRID CONCEPT design: ARIA 2 RGB comes with three AAA/LR03 batteries and is also compatible with the CORE rechargeable battery (not included)
  • The lamp detects the power source and optimizes lighting performance: with a CORE rechargeable battery, the lamp provides more brightness when turned on (600 lm in MAX POWER mode) and throughout the usage time
  • Compatible with HELMET ADAPT and BIKE ADAPT 2 mounts, allowing you to mount the lamp on a helmet or bicycle

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• References	E070BA00	E070BA01
  Color(s)	BLACK	CAMOUFLAGE
  Quantity per Internal Pack	1	1
  Brightness	450 lumens (ANSI/PLATO FL 1)
  Weight	106 g
  Beam Pattern	Wide or mixed
  Power	Three AAA/LR03 batteries (included) or CORE rechargeable battery (available as an accessory)
  Battery Compatibility	Alkaline, lithium, or Ni-MH rechargeable
  Certification(s)	CE, UKCA
  Water Resistance	IP67



  Lighting Performance According to ANSI/PLATO FL 1 Protocol
  Lighting Color	Lighting Levels	Brightness	Distance	Usage Time	Reserve Lighting
  White	MAXIMUM TIME	7 lm	10 m	100 h	-
  	STANDARD	100 lm	60 m	7 h	2 h
  	MAX POWER	600 lm	115 m	2 h	-
  Red/Green/Blue	Continuous	4 lm	5 m	50 h	-
  	Strobe	Visible at 700 m for 300 h



  Lighting Performance According to ANSI/PLATO FL 1 Protocol
  Lighting Color	Lighting Levels	Brightness	Distance	Usage Time	Reserve Lighting
  White	MAXIMUM TIME	7 lm	10 m	100 h	-
  	STANDARD	100 lm	60 m	10 h	20 h
  	MAX POWER	450 lm	100 m	2 h	-
  Red/Green/Blue	Continuous	4 lm	5 m	50 h	-
  	Strobe	Visible at 700 m for 300 h

• • ARIA 2 RGB headlamp
  • Three AAA/LR03 batteries
  • Instruction manual
• • None
• • CORE rechargeable battery
  • HELMET ADAPT mount
  • BIKE ADAPT 2 mount
  • Extra headband
  • SLOT ADAPT mounting plate
• • Download the PDF: technical-information-ANSI
  • Download the PDF: technical-notice-ARIA-1
  • Accessory Compatibility - PRO HEADLAMPS
  • Declaration of Conformity
  • Tips for Maintaining Your Equipment

Lightweight and Asymmetrical High-Strength Carabiner

An Asymmetrical Carabiner Designed for Maximum Durability and Strength in Professional and Technical Uses

The lightweight and asymmetrical Bm'D carabiner is made of aluminum. It has a D-shape especially suited for connecting various devices like descenders or positioning lanyards. Its fluid interior design and Keylock system facilitate handling. The Bm'D carabiner is equipped with an automatic TRIACT-LOCK locking system. The sleeve is reinforced for greater frontal and lateral gate strength. The Bm'D can be combined with the CAPTIV bar to favor loading of the carabiner along its major axis, limit the risk of rotation, and keep it integrated with the device.

Features

• D-shape especially suited for connecting devices like descenders or positioning lanyards.
• Aluminum carabiner whose lightness reduces the weight of equipment carried by the worker at height.
• Reinforced sleeve for greater frontal and lateral gate strength.
• Can be combined with the CAPTIV bar to favor loading of the carabiner along its major axis, limit the risk of rotation, and keep it integrated with the device.

Facilitates handling:

• Fluid interior design that limits the risk of a stable point and facilitates carabiner rotation.
• Keylock system to prevent any involuntary snagging of the carabiner.
• Automatic TRIACT-LOCK locking system with triple-action opening.
• Also available in black color version.

H-profile:

• Ensures the best strength-to-weight ratio.
• Protects markings from abrasion.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	105 g
  Locking System	TRIACT-LOCK
  Colors	Black-Grey
  Major Axis Strength	32 kN
  Minor Axis Strength	16 kN
  Open Gate Strength	10 kN
  Gate Opening	18 mm
  Certifications	CE EN 362, EAC, ANSI Z359.12, NFPA 1983 Technical Use, CSA Z259.12
  Materials	Aluminum

• • Bm'D Carabiner
  • Instruction Manual
  • Declaration of Conformity
• • Harness
  • Rope
  • Descender Device
• • CAPTIV Positioning Bar
  • Rope Protector
  • Transport Bag
• • Technical Notice BMD_TLU-1 (English)
  • Maintenance Tips for Your Equipment (English)

Stopper for PANTIN foot ascender, which helps keep the rope in the device during rope ascents. It is available for PANTIN in both right-foot and left-foot versions.

Features

• Installs directly on the PANTIN to keep the rope in the device during rope ascents.
• Available in right-foot or left-foot versions.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• References

  Ref	Left	Right
  Weight	25 g
  Materials	Aluminum and stainless steel

• • Catch for PANTIN Petzl (1)
• • Petzl PANTIN
• • PANTIN Strap
• • Technical Notice - TAQUET PANTIN-1

Improve Your Descent in Arboriculture with the Petzl CHICANE Auxiliary Brake

Auxiliary braking device that allows the use of ZIGZAG and ZIGZAG PLUS mechanical Prusiks on single ropes, providing continuous additional friction during descents and ensuring smooth rope sliding during ascents.

The additional Chicane brake allows the use of ZIGZAG and ZIGZAG PLUS mechanical Prusiks with a single rope. It provides permanent additional braking during descent. The excellent grip of the assembly, Chicane and mechanical Prusik, ensures smooth rope circulation through the brake during ascent. The ergonomic handle provides excellent grip and facilitates movement when returning from the branch. Thanks to the closing side plate, installation is easy and quick.

Features

• Permanent additional braking during descent, thanks to the two friction pins that add friction.
• Used with an Am’D or OK carabiner (not included). The H-profile of the carabiner, combined with the mechanical Prusik's attachment sleeve, provides excellent grip of the assembly, Chicane and mechanical Prusik, ensuring smooth rope circulation through the brake during ascent.
• Ergonomic handle that facilitates movement when returning from the branch.

• Closing side plate that allows easy and quick installation on the rope.
• Triple-action unlocking to limit the risk of unintentional opening of the side plate.
• Connects to the upper hole of the mechanical Prusik.
• Optimized durability, thanks to the two friction pins, available as spare parts.
• The Chicane allows work in compliance with the ANSI Z133 standard.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Characteristics
  Weight	255 g
  Working Load Limit	140 kg
  Minimum Rope Diameter	11.5 mm
  Maximum Rope Diameter	13 mm
  Certifications	CE

• • Petzl Chicane Auxiliary Brake SRS (1)
• • Climbing Equipment
• • Climbing Equipment
• • Technical notice
  • Declaration Of Conformity UE-Declaration-D022AA00-D022CA00-ZIGZAG-CHICANE
  • Declaration Of Conformity UE-Declaration-D022AA00-D022CA00-ZIGZAG-CHICANE
  • Declaration Of Conformity UKCA-Declaration-D022CA00-CHICANE

1250 mAh high-capacity lithium-ion battery for Petzl flashlights equipped with the HYBRID CONCEPT construction: TACTIKKA CORE, TACTIKKA, TACTIKKA +, and TACTIKKA +RGB. Ensures high lighting performance, even at low temperatures. It recharges directly via the integrated USB connector. The CORE battery is an economical solution as a primary power source or second battery.

Features

• Easy and universal recharge via USB connector.
• Charge indicator on the battery (red: charging; green: battery charged).
• Good performance at low temperatures.
• Economical and sustainable solution as a primary power source or second battery.
• Compatible with TACTIKKA CORE, TACTIKKA, TACTIKKA +, and TACTIKKA +RGB flashlights (version after 2017).
• Comes with a charging cable.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	23 g
  Certifications	CE
  Charging Time	3 h

• • CORE Petzl Battery (1)
• • Petzl Headlamps
• • None
• • Technical Sheet
  • UKCA Declaration of Conformity
  • EU Declaration of Conformity

Designed for caving, the SIMPLE is an easy-to-use descender. It is used with semi-static ropes with a diameter of 8.5 to 11 mm. With reduced volume and weight, it simplifies progression in narrow passages. The device's lifespan can be optimized by rotating or replacing the pulleys.

Features

Ease of use:

• Very easy to use. The descent speed is regulated by gripping the free end of the rope more or less tightly with the hand.
• Rope installation diagram engraved on the descender.
• Closing trigger on the side plate that can be opened to easily install the rope while keeping the device connected to the harness, facilitating the passage of fractionations.
• Long connection hole that allows the FREINO Z carabiner to be turned so that the descender is not lost during transfers from the gear loop to the semicircular carabiner.
• Compatible with semi-static ropes with a diameter of 8.5 to 11 mm.

Lightweight and compact:

• Only 240 g.
• Composed of two aluminum pulleys to prioritize lightness.
• Sleek design to limit the risk of snagging in narrow passages.
• Device lifespan optimized by rotating or replacing the pulleys (D004CA00).

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	240 g
  Rope Compatibility	Semi-static rope with a diameter of 8.5 to 11 mm
  Materials	Aluminum

• • Petzl Descender for Caving SIMPLE (1)
• • None
• • None
• • User Manual (English)
  • Technical Specifications (English)

Conquer the heights with style and safety

Robust quickdraw strap ideal for wall climbing, equipped with large DJINN carabiners that make clipping and unclipping easier. It offers excellent durability thanks to its wide contact surfaces and its strong strap with a STRING protector that prevents abrasion.

The go-to quickdraw for a day at the crag! The DJINN AXESS quickdraw is durable, making it ideal for sport climbing. The DJINN carabiners have a wide contact surface with the rope and the bolt hanger, optimizing rope glide and enhancing durability. The large size of the carabiners make them easy to use. The bent gate design allows you to easily clip the rope. The Keylock system helps prevent the carabiner from snagging when clipping and unclipping. The pack contains six 12 cm quickdraws with DJINN turquoise bent gate carabiners.

Features

• Extremely durable:
• The carabiners have a wide contact surface with the rope and bolt hanger for better rope glide and increased resistance to wear
• Durable sling with STRING to protect the webbing from abrasion
• Excellent ratio between functionality, durability, and weight: 12 cm quickdraw weighs 107 g
• Easy to clip and unclip:
• Large carabiners suited to bigger hands or for use while wearing gloves
• Carabiners feature the Keylock system, designed to avoid snagging on a gear loop, bolt hanger, or rope
• Straight gate design offers an excellent grip and makes clipping and unclipping easier
• Large straight gate opening makes the carabiner easy to use
• Bent gate makes clipping the rope easier
• Flat carabiner spine offers excellent stability when holding it in your hand or pinch clipping
• STRING quickdraw sling protector stabilizes the carabiner when clipping
• Available with 12 cm sling and DJINN carabiner with turquoise bent gate

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Major axis strength	23 kN
  Minor axis strength	8 kN
  Gate opening	24 mm straight gate - 27 mm bent gate
  Material(s)	Aluminum carabiner, polyester webbing, TPE (thermoplastic elastomer) STRING
  Certification(s)	Carabiner: CE EN 12275 type B, UIAA - Sling: CE EN 566, UIAA
  Length of sling	12 cm		17 cm	25 cm
  Colors	TURQUOISE	VIOLET	TURQUOISE	TURQUOISE
  Strength	22 kN
  Weight	107 g		113 g	123 g
  Inner Pack Count	1

• • DJINN AXESS x(1-6)
• • Climbing Equipment
• • Climbing Equipment
• • Technical notice
  • Tips for maintaining your equipment

Strength and Safety for Climbing Walls

Quickdraw with DJINN STEEL carabiner and GO 8 mm quick link for interior use (pack of 10)

The pack of ten DJINN STEEL AXESS quickdraws has steel carabiners, GO 8 mm quick links with K-LINK positioning accessory, and AXESS slings. The slings feature AXESS STRING webbing protection along their entire length, for intensive interior use in a climbing gym.

Features

• DJINN STEEL bent gate carabiner for interior use in climbing gyms:
• Steel carabiner provides greater durability and aluminum gate provides the same clipping feel as the DJINN carabiner
• Large gate opening makes handling the carabiner and clipping the rope easier
• Wider rope contact surface for better rope glide and reduced wear on the carabiner
• Nose and Keylock system designed to prevent the carabiner from snagging during use
• GO 8 mm quick link:
• Very large opening (17 mm)
• Steel provides great durability
• K-LINK positioning accessory orients the quick link to load the major axis and limits the risk of rotation
• Durable AXESS sling
• AXESS STRING protection covers entire length of sling to help keep the carabiner in position and protect webbing from wear during intensive use

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Weight per unit	240 g
  Length of sling	12 cm
  Sling strength	22 kN
  Major axis strength	28 kN
  Minor axis strength	10 kN
  Open gate strength	10 kN
  Gate opening	27 mm
  Capacity	24 mm
  Certification(s)	Carabiners: CE EN 12275 type B, UIAA - Sling: CE EN 566, UIAA - Quick link: CE EN 12275 type Q, UIAA - UKCA
  Inner Pack Count	1

• • 1x DJINN STEEL AXESS
• • Equipo de Escalada
• • Equipo de Escalada
• • Technical notice
  • Declaration Of Conformity UE-Declaration-M60AS-B-DJINN-STEEL
  • Declaration Of Conformity UE-Declaration-C041AA00-C041AA01-AXESS
  • Declaration Of Conformity UKCA-Declaration-M60AXX DINN STEEL
  • Declaration Of Conformity UKCA-Declaration-M060LXXX-DJINN DROIT COURBE
  • Tips for maintaining your equipment

The adjustable FOOTAPE foot loop is used with the ASCENSION handled ascender for rope ascents.

Features

• Attaches to the ASCENSION handled ascender for rope ascents.
• Abrasion-resistant and more rigid reinforcement in the step to facilitate foot insertion.
• Adjustable elastic to secure the foot in the loop, regardless of the type of footwear.
• DoubleBack buckle for quick and precise length adjustment of the foot loop.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	65 g
  Materials	polyamide and steel

• • Adjustable Petzl FOOTAPE Foot Loop (1)
• • Petzl Ergonomic ASCENSION Handled Ascender
• • Climbing Equipment
• • Tips for maintaining your equipment

The adjustable FOOTCORD foot loop is used with the Ascension handled ascender for rope ascents. Its 100% Dyneema construction increases its durability.

Features

• Attaches to the Ascension handled ascender for rope ascents.
• 100% Dyneema construction increases its durability.
• Adjustable elastic to secure the foot in the loop, regardless of the type of footwear.
• Length adjustment plate for quick and precise adjustment of the foot loop length.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	40 g
  Materials	Dyneema and aluminum

• • Adjustable Petzl FOOTCORD Foot Loop (1)
• • None
• • Adjustable Petzl FOOTAPE Foot Loop
• • Tips for Maintaining Your Equipment

High Visibility Vest for NEWTON Harnesses

High Visibility Vest for Improving Safety in Work at Height with NEWTON, NEWTON FAST, and NEWTON EASYFIT Harnesses

Fluorescent color vest with retro-reflective bands that provide high visibility for the worker, regardless of the lighting. It installs quickly and easily on the NEWTON, NEWTON FAST, and NEWTON EASYFIT harnesses. The sternal buckle, multiple attachment points, and connectors remain accessible to allow optimal freedom of movement.

Features

• Simple and quick to don:
• FAST LT PLUS sternal automatic buckle, sternal and dorsal attachment points, and connectors remain accessible when the vest is installed.
• Zipper closure on the back allows ventilation.
• Compatible with NEWTON, NEWTON FAST, and NEWTON EASYFIT harnesses.
• Two zippered pockets allow storage of small items and personal effects.
• Machine washable at 30° C.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications

  • Weight: 380 g
  • Material(s): nylon
  • Certification(s): CE ISO 20471, ANSI 107, CSA Z96, UKCA

  References

  References	C073GA00	C073HA00
  Colors	Yellow	Orange
  Pack	1	1

• • HI-VIZ Vest
  • Instruction manual
  • Declaration of conformity
• • NEWTON Harness
  • NEWTON FAST Harness
  • NEWTON EASYFIT Harness
• • TOOLBAG tool pouch
  • Energy-absorbing fall arrest lanyards
  • MGO connectors in different sizes and specifications
  • Retractable fall arrest system
  • Safety rope for working at height
  • Safety helmet with integrated visor
  • Cut-resistant safety gloves
  • Safety boots with anti-slip soles
  • High visibility vest
  • Headlamp with adjustable brightness
• • Technical-notice-NEWTON HI-VIZ-1

Powerful Lighting and Ergonomic Design for Outdoor Adventures

Ultralight 350-lumen headlamp with AIRFIT® headband and balanced design for maximum comfort during dynamic activities.

The Iko headlamp is a concentrate of technologies that offers a power of 350 lumens with only 90 g. Equipped with the AIRFIT® headband, an ultra-thin front block, and a power source shifted to the back, the headlamp is balanced and comfortable to the point of forgetting about it. The multiple LEDs allow for a homogeneous distribution of the lighting for optimal visual comfort. The Iko works with three batteries and is also compatible with the CORE Petzl Battery, thanks to the HYBRID CONCEPT construction. Versatile, it can be worn around the neck or transformed into a lamp.

Features

Ergonomics and comfort, thanks to the AIRFIT® headband (Petzl patent):

• Innovative and sleek design with a semi-rigid headband and an ultra-thin front block. The power source is shifted to the back to distribute the weight of the headlamp over the entire head and provide balanced and comfortable wear to the point of forgetting about it.
• Hydrophobic headband that does not absorb sweat or rain. Being so thin, the headband significantly reduces contact areas and promotes air circulation during dynamic activities.
• Easy and quick adjustment at the back.

Optimized visual comfort:

• Lightweight and powerful: 350 lumens for 90 g.
• Multiple LEDs that offer a homogeneous distribution of the lighting.
• Two types of light beams (wide or mixed) and several levels of white lighting to meet different needs: proximity vision, movement, and long-distance vision.
• Three levels of lighting easily and quickly accessible via a single button.

Versatile and easy to use:

• HYBRID CONCEPT construction: the Iko works with three batteries and is also compatible with the CORE battery. The headlamp detects the power source and adjusts the lighting performance (Iko with batteries = 350 lumens; Iko with CORE battery = 500 lumens).
• Allows several modes of wear and attachment depending on use: on the head, around the neck, on a table, attached to a tent pole, or on a tree.
• Storage bag that allows transforming the headlamp into a lamp.
• Reflective elements on the back of the headlamp for better visibility at night.
• Light indicator when turning the headlamp on and off to check the remaining power.
• Two LOCK functions to prevent accidental activation.
• Stores flat in a minimalist bag for more compactness.
• Compatible with all Petzl helmets.

• Specifications
• In the Box
• Required Items
• Optional Items
• Manuals

• Specifications
  Power	350 lumens (ANSI-FL1 STANDARD)
  Weight	90 g
  Type of Light Beam	wide or mixed
  Power Supply	3 AAA/LR03 batteries (included) or CORE battery (available as an accessory)
  Battery Compatibility	alkaline, lithium, or rechargeable Ni-MH
  Certifications	CE
  Water Resistance	IPX4 (resistant to water splashes)
  Color	Black




  Lighting Performance with 3 AAA/LR03 Batteries

  Lighting performance according to the ANSI/PLATO FL 1 protocol
  Lighting Color	Lighting Levels	Luminous Power	Range	Autonomy	Reserve
  white	MAX BURN TIME	6 lm	10 m	100 h	N/A
  	STANDARD	100 lm	45 m	8 h	20 h
  	MAX POWER	350 lm	80 m	2 h	50 h




  Lighting Performance with CORE Battery

  Lighting Performance According to ANSI/PLATO FL 1 Protocol
  Lighting Color	Lighting Levels	Luminous Power	Range	Autonomy	Reserve
  white	MAX BURN TIME	6 lm	10 m	100 h	N/A
  white	STANDARD	100 lm	45 m	9 h	2h30
  white	MAX POWER	500 lm	100 m	2h30	4h30

• • Petzl IKO (CORE) Headlamp (1)
• • None
• • CORE Battery
• • Technical Specifications Manual (English)
  • Technical Sheet notice-technique-IKO-IKO CORE-1
  • Technical Sheet HEADLAMPS - ACCESSORY COMPATIBILITY
  • EU Declaration of Conformity UE-Declaration-E104AAXX_E104BAXX-IKO_IKO CORE
  • UKCA Declaration of Conformity UKCA-Declaration-E104AA-E104BA-IKO-IKO CORE
  • Tips for maintaining your equipment

Total Control at Any Height: The Ultimate Self-Braking Descender for Professionals

Designed for Work at Height and Rope Access, Featuring AUTO-LOCK System and Ergonomic Handle

The self-braking descender I’D S is primarily intended for work at height and difficult access. It is equipped with an ergonomic handle that allows comfortable control of the descent. The integrated anti-panic function and error indicator cam limit the risk of accidents in case of misuse. The AUTO-LOCK system allows easy positioning at the workplace without having to manipulate the handle or perform a locking knot. Once locked, the rope can be retrieved without having to manipulate the handle. The closing trigger allows the rope to be installed while keeping the device connected to the harness. The I’D S is compatible with ropes from 10 to 11.5 mm and allows handling loads up to 250 kg.

Features

• Designed for work at height and difficult access.

Ease of use:

• It has a closing trigger on the movable side plate that allows the rope to be easily installed while keeping the device connected to the harness.
• Easy rope installation, thanks to the guide and indicative markings.
• Error indicator cam to limit the risk of accidents due to incorrect rope placement.
• Ergonomic handle that allows the rope to be released and comfortably control the descent. Two possible descent modes: on the side plate or in the V-shaped braking groove.
• Anti-panic function that automatically stops the descent if the user pulls too hard on the handle.
• Allows smooth movement on horizontal or inclined planes.
• AUTO-LOCK system that allows easy positioning at the workplace without having to manipulate the handle or perform a locking knot: as soon as the user releases the handle, the rope is automatically locked in the device. The automatic return of the handle limits the risk of unintentional snagging.
• Automatic handle transition to the storage position when the rope is removed from the device, reducing the risk of unintentional snagging when the descender is carried on the harness.

Usage:

• Once locked, the rope can be retrieved without having to manipulate the handle, allowing a lifting system to be converted into a reversible one or easily perform short rope ascents.
• Cam that can be manipulated to easily retrieve the rope or belay a lead climber in climbing technique.
• Screw that allows the movable side plate to be locked to integrate the I’D S into rescue kits.
• Possibility of adding an additional brake, open or closed, for better control of the descent depending on the load and rope diameter.
• Protection reinforcement, made of stainless steel in the rope friction zone, which increases wear resistance.
• Heavy load descent up to 250 kg.
• Rope compatibility: 10 to 11.5 mm in diameter.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications
  Weight	600 g
  Colors	Yellow	Black
  Materials	Aluminum, steel, and nylon
  Maximum Load for One Person	Up to 150 kg
  Maximum Load for One Person	Up to 150 kg
  Rope Compatibility	10 to 11.5 mm
  Certifications	E EN 341 type 2 class A, CE EN 12841 type C, CE EN 15151-1, ANSI Z359.9, ANSI Z459.1, NFPA 2500 General Use, NFPA 2500 Technical Use, EAC, GB/T 38230 II A, XF494 - FZL-X-Q10/11.5

• • Petzl Self-braking Descender I’D® S (1)
• • None
• • None
• • Technical notice
  • Declaration Of Conformity UE
  • Declaration Of Conformity UCKA
  • Tips for maintaining your equipment

Double-layer construction gives the JET throw-bag excellent longevity. Its streamlined shape facilitates passage through tree branches. It is available in three versions: 250, 300 and 350 g.

Features

• Throw bag has rugged, two-layer construction for long life
• Streamlined shape facilitates passage through tree branches
• Different colored stitching on the webbing differentiates bag weights
• Secondary connection point for quick attachment of the rope
• Yellow for excellent visibility
• Available in three versions: 250, 300 and 350 g

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications

  • Color(s): yellow
  • Material(s): lead

  References

  References	S02Y 250	S02Y 300	S02Y 350
  Weight	250 g	300 g	350 g
  Inner Pack Count	1

• • JET Throw-Bag (250 g, 300 g, or 350 g)
  • Instruction manual
• • Throwing line
  • Protective gloves
• • Safety harness
  • Anchor strap
  • Protective helmet
  • Transport bag
  • CAPTIV Bar
  • Gloves with unlocking spike
  • Unlocking ring
• • Retiring_recycling specific informations
  • WARNING for California Residents (JET)

Master Technical Rescue with the Petzl MAESTRO Descender

Descender with integrated progress capture pulley, designed for technical rescue operations. Facilitates the handling of heavy loads in descent or ascent, compatible with ropes from 10.5 to 13 mm and supports loads up to 280 kg.

MAESTRO L is a descender designed for technical rescue operations. It facilitates the handling of heavy loads, for lowering or transporting, and can be used both in the primary system and in a backup belay. This versatility allows rescuers to adapt to any situation they may encounter at the rescue scene. The ergonomic handle and integrated braking allow for a comfortably controlled descent. The change from the descent position to the hauling position is immediate, without the need to transfer the load. The integrated progress capture pulley has a large diameter pulley mounted on sealed ball bearings, ensuring excellent hauling efficiency.

Features

• The locking system with integrated progress capture pulley allows the same device to be used for descent and hauling.
• It can be used both in a simple or double primary system and in a backup belay.
• The lower connection point can be used to create different types of hauling systems.
• The hole in the handle for installing a remote control cord.

• Easy rope installation, thanks to the markings on the device.
• The ergonomic handle allows the rope to be progressively released and provides comfortable control of the descent.
• Immediate change from the descent position to the hauling position without having to transfer the load.
• AUTO-LOCK system allows the rope to automatically lock when the handle is not in use. Once locked, the rope can be lifted without having to manipulate the handle.

• Integrated progress capture pulley with a very large diameter pulley mounted on sealed ball bearings; rotates in one direction for excellent hauling efficiency.
• The pulley is faceted, creating additional friction zones for the rope and, therefore, additional braking during descents. Integrated brake in the device to adjust friction based on the load and rope diameter. Handling loads up to 280 kg.
• Rope compatibility: 12.5 to 13 mm in diameter.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Characteristics
  Materials	Aluminum, stainless steel, nylon.
  Weight	1100 g
  Min. Rope Diameter	12.5 mm
  Max. Rope Diameter	13 mm
  Maximum Working Load	280 kg
  Breaking Strength	18 kN x 2 = 36 kN
  Certifications	CE *, EN 341 type 2 class A, NFPA 1983 General Use, EAC. * CE based on the requirements of standards EN 12278, EN 567, EN 12841 type B, and EN 15151

• • Petzl MAESTRO L Descender (1)
• • Climbing Equipment
• • Climbing Equipment
• • Technical notice
  • Declaration Of Conformity
  • Declaration Of Conformity
  • Tips for maintaining your equipment

Ergonomic and Quick-to-Don Harness with High Visibility for Working at Height

Ergonomic and High Visibility Safety Harness with Quick-Donning System for Professionals Working at Height

The NEWTON EASYFIT is an ergonomic and comfortable fall arrest harness, quick to put on. It is equipped with padded shoulder straps and FAST LT PLUS buckles on the leg loops that allow the harness to be donned with feet on the ground, without losing adjustment. Its lightweight and breathable construction offers two zippered pockets for storing small items. Access to tools is immediate, thanks to the gear loops and the slots for the TOOLBAG pouch. Its textile sternal attachment point and its dorsal attachment points, both metal and textile, ensure great versatility. It allows ergonomic stowing of MGO connectors and is equipped with fall indicators. It is certified according to North American, European, and Russian standards.

Features

• Ergonomic and lightweight construction:
  • Anatomical design that allows the harness to be worn close to the body while maintaining optimal freedom of movement.
  • Textile sternal attachment point, lightweight and abrasion-resistant.
  • Anodized aluminum dorsal attachment point for great durability.
  • Textile dorsal attachment point for connection of a retractable fall arrest system.
  • Padded shoulder straps separated from the neck to limit chafing.
  • Possibility to connect a LIFT spreader for descent in an upright position.
• Optimal comfort:
  • Lightweight and breathable construction that maintains the shape of the harness.
  • Two zippered pockets, one on each side of the harness, for storing small items and personal effects.
  • Removable leg loop padding.
  • Transparent area for easily and quickly identifying the worker.
• Quick to don and easy to use:
  • Donning the harness with feet on the ground, thanks to leg loops and sternal strap equipped with FAST LT PLUS buckles. Opening and closing are easy and quick, without losing adjustment, even with gloves. The unlocking system limits the risk of unintentional opening.
  • Shoulder straps equipped with DOUBLEBACK self-locking buckles for simple and quick adjustment.
  • Two gear loops and two slots for TOOLBAG tool pouch to facilitate access to tools.
  • System for stowing MGO connectors of fall arrest lanyards on each shoulder strap. In the event of a fall, this system allows the absorber to deploy by releasing the MGO connectors.
• International version with fall indicator: a red strap appears as a result of a fall on the sternal or dorsal attachment point, indicating the harness must be discarded.

• Specifications
• In the Box
• Required Items
• Optional Items
• Documents

• Specifications

  • Sternal attachment point: Connection for fall-arrest system
  • Metal dorsal attachment point: For connecting a fall-arrest system
  • Textile dorsal attachment point: For connecting a self-retracting fall-arrest system
  • Certification(s): CE EN 361, EAC, ANSI Z359.11, CSA Z259.10, UKCA, JSFAD, GB 6095-2021: Z, XF 494-2004: FZL-DD-II
  • Material(s): Nylon, polyester, aluminum, steel

  References

  Ref	1	2
  Weight	1.3 kg	1.4 kg
  Waist Size	70-93 cm	83-120 cm
  Thigh Size	47-62 cm	50-65 cm
  Height	165-185 cm	175-200 cm

• • Petzl Harness
• • None
• • LIFT spreader for descending in an upright position
  • TOOLBAG tool pouch in different sizes
  • Energy-absorbing fall arrest lanyards
  • MGO connectors in different sizes and specifications
  • Retractable fall arrest system
  • Safety rope for working at height
  • Safety helmet with integrated visor
  • Cut-resistant safety gloves
  • Safety boots with anti-slip soles
  • High visibility vest
  • Headlamp with adjustable brightness
• • Technical Notice NEWTON-ANSI-2 (English)
  • Technical Notice NEWTON-CSA-2 (English)
  • Technical Notice NEWTON CE Inter (English)
  • Tips for maintaining your equipment (English)
  • User Guide

Designed for rope ascents, the ventral ascender is lightweight and easy to use. The connection holes ensure effective attachment during ascents. The stainless steel protection plate improves wear resistance by protecting the rope friction zone.

Features

• Efficiency and ease of use for rope ascents.

Used as a complement to a Basic ascender or an Ascension handled ascender for rope ascents:

• Lower hole adapted to keep the ventral ascender flat.
• Upper hole for attaching TORSE shoulder straps to keep the ascender in position.
• Cam opening by pinching for easy and quick manipulation.

Optimized performance for large diameter ropes:

• Stainless steel protection plate to improve wear resistance.
• Stainless steel cam to improve corrosion resistance.

Adapted to any usage condition:

• Toothed cam with evacuation slot to optimize functioning in any condition (frozen, muddy rope, etc.).
• Stainless steel cam to improve corrosion resistance.

• Specifications
• In the Box
• Required Items
• Optional Items

• Ref	Thin Ropes	Large Diameter Ropes
  Weight	85 g	140 g
  Rope Compatibility	8 to 11 mm	8 to 13 mm
  Materials	aluminum body, stainless steel cam and protection plate, polyamide stop
  Certifications	CE EN 567, UIAA, NFPA 2500 Technical Use, XF 494

• • Petzl Reinforced Ventral Ascender for Ropes (1)
• • None
• • Adjustable Petzl FOOTAPE Foot Loop
  • Petzl Compact Versatile Basic Ascender
• • Technical notice
  • Declaration Of Conformity
  • Tips for maintaining your equipment
